Chimney
Butterfly Damper Image
Call for price
Chimney Liners Image
Call for price
Covers Caperose Image
Call for price
Covers Edinburgh Image
Call for price
Covers Luxemburg Image
Call for price
Covers Rockport Image
Call for price
Covers Roman Image
Call for price
Covers Tudor Image
Call for price
Covers Turretfin Image
Call for price
Covers Tuscan Image
Call for price
Covers Windsor Image
Call for price
Monsoon Cap Image
Call for price
Pots Caperose Image
Call for price
Pots Edinburgh Image
Call for price
Pots Luxemburg Image
Call for price
Pots Provincial Image
Call for price
Pots Rockport Image
Call for price
Pots Roman Image
Call for price
Pots Toppers Image
Call for price
Pots Tudor Image
Call for price
Pots Turretfin Image
Call for price
Pots Tuscan Image
Call for price
Pots Wellington Image
Call for price
Pots Windsor Image
Call for price
Rockport Image
Call for price
Ventinox Image
Call for price
VVR Wall Fan Image
Call for price
Chimney
2 Single Flue Chimney
Call for price
2 Stock Topmount
Air Insulated Caps for Metal Chimneys - 1
Call for price
Air Insulated Caps for Metal Chimneys - 1 Image

Air Insulated Caps for Metal Chimneys
1″ Mesh for Outside California

This chimney cap is designed for air-insulated chimneys (double or triple wall). It has a tight, friction-fit which we recommend you also use with silicone to keep it in place.

Note: To get the correct size, measure the inside diameter of the center pipe. You must use the correct cap for each system. Using a single wall cap on an air-insulated
chimney can cause it to over heat.



Air Insulated Caps for Metal Chimneys - CA 1/2
Call for price
Air Insulated Caps for Metal Chimneys - CA 1/2 Image

Air Insulated Caps for Metal Chimneys
California 1/2″ Mesh

This chimney cap is designed for air-insulated chimneys (double or triple wall). It has a tight, friction-fit which we recommend you also use with silicone to keep it in place.

Note: To get the correct size, measure the inside diameter of the center pipe. You must use the correct cap for each system. Using a single wall cap on an air-insulated
chimney can cause it to over heat.

Animal Guards - 304 Stainless Steel - 3/4
Call for price
Animal Guards - 304 Stainless Steel - 3/4 Image

Animal Guards – 304 Stainless Steel – 3/4″ Mesh
Stackable 4″ Screen Height

Masonry chimney caps are good for keeping out the rain but they need animal guard to keep all the critters outside and the sparks inside. So if your area has a lot of Blue Stone or masonry chimney caps, keep a 5-pack on the truck so you don’t have to make seconds trips to install them.

Animal guards have no lid or top like a chimney cap. They are to keep out animals and act as a spark arrester. They have 4” screen heights so they easily slip under existing masonry chimney caps (Sometimes called Blue Stone caps).















Animal Guards - Black Galvanized - 3/4
Call for price
Animal Guards - Black Galvanized - 3/4 Image

Animal Guards Black Galvanized – 3/4″ Mesh Stackable 4″ Screen Height

Masonry chimney caps are good for keeping out the rain but they need animal guard to keep all the critters outside and the sparks inside. So if your area has a lot of Blue Stone or masonry chimney caps, keep a 5-pack on the truck so you don’t have to make seconds trips to install them.

Animal guards have no lid or top like a chimney cap. They are to keep out animals and act as a spark arrester. They have 4” screen heights so they easily slip under existing masonry chimney caps (Sometimes called Blue Stone caps).

BESB box ventilators
Call for price
BESB box ventilators Image

BESB BOX VENTILATORS

BESB box ventilators are made from Aluzinc® AZ185 class C4 in accordance with EN/ISO12944-2 and insulated for sound and condensation with 50 mm mineral wool.


As standard BESB can handle a gas temperature of up to 80°C, but can be ordered in a special version for temperatures right up to 200°C.

When used as a smoke extract fan, BESB can as standard handle up to 300°C for 60 min.

BESB box ventilators



Capacity m3/h
Min. Max.
BESB250-4-1 300 1840
BESB250-4-1EC 350 2260
BESB250-4-3 350 2200
BESB315-4-1EC 570 3590
BESB315-4-3 570 3500
BESB400-4-1EC 950 6000
 BESB400-4-3 900 5180
BESB500-4-1EC 1180 7300
BESB500-4-3 2600 7900
BESB500-4-3EC 1330 10800

DESIGN

Fan Impeller

The ventilator impeller is a B-impeller made from cast aluminium.

It has backward curved blades, thus ensuring low energy consumption and the further advantage that less dirt is attracted, with impaired impeller efficiency as a result.

Spigots

The spigots on BESB have rubber gaskets, with a transition piece on the extract side specially developed for minimum pressure drop.

OSCILLATION DAMPERS

To minimize noise and vibration, the box ventilator is fitted as standard with efficient oscillation dampers mounted on brackets.

SPLIT HINGES

The BESB box ventilator has split hinges, which enable the door to be removed for installation and servicing, even in very confined conditions or for transport to difficult locations.

CONDENSATION OUTLET

The BESB box ventilator is designed to transport air with an air humidity of less than 80% RH.

BESB is available as a special model with a condensation outlet for air with over 80% RH.

Split Version

If there are problems moving the BESB box ventilator in one piece, it may be ordered in a SPLIT version.

– The box ventilator must be assembled by an EXHAUSTO-approved fitter
– The box ventilator must receive final testing before handover by the fitter.

ENERGY

BESB box ventilator

The BESB box ventilator is a low-energy ventilator, in which ventilator housing, centrifugal impeller and motor all work together as one technology.

All BESB box ventilators fulfil the future requirements for 2015 laid down in the Ecodesign Directive EC327/2011.

BESB is listed by the Danish electrical power utility companies as an ‘energy-saving fan’® – that is a highly energy-efficient ventilator.

MOTOR TYPES

BESB box ventilator

BESB box ventilators have their motor connected directly to the ventilator impeller.

BESB box ventilators are available with three types of motor:

– EC motor
– single-phase motor
– 3-phase motor

The motors are made to protection class IP54 and all materials are as a minimum class F (155 °C). All motor types have integral current overload protection.


EC motor

The EC motor for BESB is a permanent-magnet motor of class IE5 with motor control for 1 x 230 V or 3 x 400 V connection. The motor control and the motor are protected from overloading, blocking, over and under voltage, and over heating.

The motor control is factory programmed by EXHAUSTO for optimal operation of the ventilator. It only requires mains connection and a control signal from an EXHAUSTO EFC1P or MAC12 controller or a 0-10V signal.

The motor controls also provide a Modbus interface for fan control and alarm read-offs etc.


Single-phase and 3-phase motor:

Single-phase motors can be selected for BESB250. All motors are 4-pole with 1400 rpm, and permit direct voltage control using EXHAUSTO controllers EFC16, EFC35 and MAC12 (with MPR4 or MPR8 module).

3-phase motors can be selected for BESB500. The motor is designed for a fixed rpm of 1400 or for frequency control (max. 50 Hz) by external frequency converter. The 3-phase motors must use external motor protection, or they can be controlled by an external frequency converter (with integral motor protection) to max. 50 Hz.

BESB250 Box Ventilator
Call for price
BESB250 Box Ventilator Image

BESB250-4-1 and BESB250-4-1EC

Technical Data

MODEL  BESB250-4-1 BESB250-4-1EC
Fan data
Max. overall efficiency  51,6  68,4%
ECO measurement set-up (A-D)  D  D
Efficiency requirements 64, N(2015)  64, N(2015)
ECO efficiency at optimal operating point 69,5 92,7

Motor
Motor Single-phase motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
198 W
1355 m3/h
272 Pa
1379 rpm
164 W
1354 m3/h
298 Pa
1443 rpm
Nominal rpm (N)  1400 rpm
Electric supply (U)   1×230 V ~ 50 Hz
Overload protection Integral thermal cutout (TP211) in motor power circuit Integrated in motor control
Max absorbed current* (I) 0.98 A  1.2 A.
Max. absorbed power (P1)**  0.22 kW  0.17 kW
Motor output (P2)**  0.10 kW 0.18 kW

Other data
Weight 50 kg 52 kg

Technical Data

BESB250-4-3 with three phase motor

MODEL BESB250-4-1EC
Fan data
Max. overall efficiency 53,4 %
ECO measurement set-up (A-D)  D
Efficiency requirements  64, N(2015)
ECO efficiency at optimal operating point 78,8

Motor
Motor Three phase motor, frequency converter required in accordance with Ecodesign
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
189 W
1,222 m3/h
297 Pa
1,438 rpm
Nominal rpm (N)  1,400 rpm
Electric supply (U) 3×400 / 3 x 230 V
Overload protection No, must be overload-protected in accordance with applicable regulations
Max absorbed current* (I) 0.8 / 1.4 A.
Max. absorbed power (P1)**  0.20 kW
Motor output (P2)** 0.18 kW

Other data
Weight 50 kg
Supply (power cable / control cable) No supply



BESB315 Box Ventilator
Call for price
BESB315 Box Ventilator Image

BESB315-4-1EC Technical Data

MODEL BESB315-4-1EC
Fan data
Max. overall efficiency  69,0 %
ECO measurement set-up (A-D)  D
Efficiency requirements  64, N(2015)
ECO efficiency at optimal operating point 89,7

Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
335 W
2173 m3/h
383 Pa
1417 rpm
Nominal rpm (N)  1400 rpm
Electric supply (U)   1×230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 2.2 A
Max. absorbed power (P1)**  0.35 kW
Motor output (P2)** 0.37 kW

Other data
Weight 57 kg

Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +80° C
  • Ambient temperature: Max. +40° C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions

BESB315-4-3 with three phase motor Techical Data

MODEL BESB315-4-3
Fan data
Max. overall efficiency 55,0 %
ECO measurement set-up (A-D)  D
Efficiency requirements  64, N(2015)
ECO efficiency at optimal operating point 76,7

Motor
Motor Three phase motor, frequency converter required in accordance with Ecodesign
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
365 W
1,950 m3/h
371 Pa
1,408 rpm
Nominal rpm (N)  1,400 rpm
Electric supply (U) 3 x 400 / 3 x 230 V
Overload protection No, must be overload-protected in accordance with applicable regulations
Max absorbed current* (I) 1.1 / 1.9 A.
Max. absorbed power (P1)**  0.39 kW
Motor output (P2)** 0.37 kW

Other data
Weight 59 kg
Supply (power cable / control cable) No supply



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +80° C
  • Ambient temperature: Max. +40° C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
BESB400 Box Ventilator
Call for price
BESB400 Box Ventilator Image

BESB400 Technical Data

MODEL BESB400-4-1EC
Fan data
Max. overall efficiency 71,6 %
ECO measurement set-up (A-D)  D
Efficiency requirements  64, N(2015)
ECO efficiency at optimal operating point 91,7

Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
375 W
2868 m3/h
337 Pa
1195 rpm
Nominal rpm (N)  1435 rpm
Electric supply (U)   1×230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 4.5 A
Max. absorbed power (P1)**  0.67 kW
Motor output (P2)** 0.75 kW

Other data
Weight 73 kg

Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +80° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1.11
  • other points in acc. with EC327/2011 – see product instructions

BESB400-4-3 with three phase motor Technical Data

MODEL BESB400-4-3
Fan data
Max. overall efficiency 56,0 %
ECO measurement set-up (A-D)  D
Efficiency requirements  64, N(2015)
ECO efficiency at optimal operating point 67,2

Motor
Motor Three phase motor, frequency converter required in accordance with Ecodesign
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
845 W
3,312 m3/h
514 Pa
1,436 rpm
Nominal rpm (N)  1,400 rpm
Electric supply (U) 3×400 / 3 x 230 V
Overload protection No, must be overload-protected in accordance with applicable regulations
Max absorbed current* (I) 0.8 /  3.3 A.
Max. absorbed power (P1)**  0.88 kW
Motor output (P2)** 0.75 kW

Other data
Weight 80 kg
Supply (power cable / control cable) No supply



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +80° C
  • Ambient temperature: Max. +40° C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
BESB500 Box Ventilator
Call for price
BESB500 Box Ventilator Image

BESB500-4-1EC and BESB500-4-3EC Technical Data

MODEL  BESB500-4-1EC BESB500-4-3EC
Fan data
Max. overall efficiency  71,5 % 74,6 %
ECO measurement set-up (A-D)  D  D
Efficiency requirements  64, N(2015)  64, N(2015)
ECO efficiency at optimal operating point  87,4 87,2

Motor
Motor EC motor with integral VSD EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
824 W
4252 m3/h
499 Pa
1261 rpm
1472 W
5199 m3/h
760 Pa
1551 rpm
Nominal rpm (N) 1420 1757
Electric supply (U)   1×230 V ~ 50 Hz 3 x 400 V
Overload protection Integrated in motor control Integrated in motor control
Max absorbed current* (I) 8.5 A 3.8 A
Max. absorbed power (P1)** 1.23 kW  2.19 kW
Motor output (P2)** 1.1 kW 2.2 kW

Other data
Weight 88 kg 91 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +80° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1.11
  • other points in acc. with EC327/2011 – see product instructions

BESB500-4-3 Technical Data

MODEL  BESB500-4-3
Fan data
Max. overall efficiency 66,9 %
ECO measurement set-up (A-D)  D
Efficiency requirements  64 N(2015)
ECO efficiency at optimal operating point 76,1
Motor
Motor  Three-phase motor designed for 1400 rpm or for an external frequency converter (max. 50 Hz).
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
1331 W
4822 m3/h
664 Pa
1459 rpm
 Nominal rpm  1400 rpm
Electric supply (U)  3 x 400 V ~ 50 Hz
Overload protection  Must be overload-protected in accordance with applicable regulations
Max absorbed current* (I) 6.8 A
Max. absorbed power (P1)**  1.47 kW
Motor output (P2)**  1.1 kW

Supply
Supply (power cable) None
Supply (control cable)  –
Length

Other data
Weight  95 kg.



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +80° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1.11
  • other points in acc. with EC327/2011 – see product instructions
BESF Box Ventilator
Call for price
BESF Box Ventilator Image

BESF box ventilators

Overview



Capacity m3/h
Min. Max.
BESF146-4-1 68 540
BESF160-4-1 120 970
BESF160-2-1EC 150 1,475
BESF180-4-1EC 135 1,740
BESF200-4-1EC 240 1,800
BESF225-4-1EC 265 2,520
BESF250-4-1 770 3,390
BESF250-4-1EC 275 3,240
BESF250-4-3 770 3,390
BESF280-4-3 900 3,960
BESF280-4-3EC 580 5,080

Design

BESF box ventilators are made from Aluzinc® AZ185 class C4 in accordance with EN/ISO12944-2 and insulated for sound and condensation with 30 mm mineral wool.

As standard, BESF can handle gas temperatures up to 60°C.

When used as a smoke extract fan:
BESF146-180 can as standard cope with up to 200°C for 60 min.
As standard, BESF200-280 can handle up to 300°C for 60 min.

Fan Impeller

The ventilator impeller is an F-impeller made from galvanised steel.

It has forward-curved blades, which means that the box ventilator is able to generate a high pressure for its compact size.

Spigots

The spigots on BESF have rubber gaskets to ease mounting of ducts.





Oscillation Dampers

To minimize noise and vibration, the box ventilator is fitted as standard with efficient oscillation dampers mounted on brackets.

OGSR TRANSITION PIECE

To minimise system pressure drop when connecting to a duct system, we recommend the use of an OGSR transition piece (accessory).

OGSR is a specially developed circular transition piece with integral guide panels; it can be supplied for BESF200, 225, 250 and 280 and allows maximum capacity and efficiency to be achieved.

OGSR is not available with other BESF models.

Motor Types

BESF box ventilator

BESF box ventilators have their motor connected directly to the ventilator impeller.

BESF box ventilators are available with three types of motor:

– EC motor
– single-phase motor
– 3-phase motor

The motors are made to protection class IP54 and all materials are as a minimum class F (155 °C). All motor types have integral current overload protection.


EC motor

The EC motor for BESF is a permanent-magnet motor of class IE5 (BESF25041EC: IE4) with motor control for 1 x 230 V or 3 x 400 V connection. The motor control and the motor are protected from overloading, blocking, over and under voltage, and over heating.

The motor control is factory programmed by EXHAUSTO for optimal operation of the ventilator. It only requires mains connection and a control signal from an EXHAUSTO EFC1P or MAC12 controller or a 0-10V signal.

The motor controls also provide a Modbus interface for fan control and alarm read-offs etc.


Single-phase and 3-phase motor:

Single-phase motors can be selected for BESF146/BESF160/BESF250. All motors are 4-pole with 1400 rpm, and permit direct voltage control using EXHAUSTO controllers EFC16, EFC35 and MAC12 (with MPR4 or MPR8 module).

3-phase motors can be selected for BESF250/BESF280. The motor is designed for a fixed rpm of 1400 or for frequency control (max. 50 Hz) by external frequency converter. The 3-phase motors must use external motor protection, or can be controlled by an external frequency converter (with integral motor protection) to max. 50 Hz.

BESF146 Box Ventilator
Call for price
BESF146 Box Ventilator Image

BESF146

MODEL BESF146-4-1
Motor
Motor Single-phase motor
Nominal rpm (N)  1400 rpm at 50 Hz
Electric supply (U)  1×230 V
Overload protection  Integral thermal cutout (TP211) in motor power circuit
Max absorbed current* (I)  0.35 A.
Max. absorbed power (P1)**  0.10 kW
Motor output (P2)**  0.04 kW

Supply
Supply (power cable) 3 x 0.75 mm2
Length 1.4 m
Other data
Weight  13 kg.

Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40° C
  • Pressure ratio: < 1,11
BESF160 Box Ventilator
Call for price
BESF160 Box Ventilator Image

BESF160-2-1EC and BESF160-4-1

Technical Data

MODEL BESF160-2-1EC BESF160-4-1
Fan data
Max. overall efficiency 50,3 %
ECO measurement set-up (A-D)  D
Efficiency requirements 49, N(2015)
ECO efficiency at optimal operating point 63,4
Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
385 W
887 m3/h
786 Pa
2845 rpm
Nominal rpm (N)  2800 rpm  1400 rpm
Electric supply (U)   1×230 V ~ 50 Hz
Overload protection Integrated in motor control Integral thermal cutout (TP211) in motor power circuit
Max absorbed current* (I) 3.8 A 0.8 A
Max. absorbed power (P1)**  0.66 kW 0.19 kW
Motor output (P2)** 0.75 kW 0.9 kW
Supply
 Supply (power cable)  3 x 0.75 mm2
 Length  1.4 m.
Other data
Weight 22 kg 17 kg

Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data for for t = 20°C
  • Density = 1.2 /m3
  • Values are based on the use of a transition piece equivalent to OGSR
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40° C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
BESF180 Box Ventilator
Call for price
BESF180 Box Ventilator Image

BESF180-4-1EC

Technical Data

MODEL BESF180-4-1EC
Fan data
Max. overall efficiency 48,5 %
ECO measurement set-up (A-D)  D
Efficiency requirements 49, N(2015)
ECO efficiency at optimal operating point 66,5

Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
89 W
615 m3/h
253 Pa
1438 rpm
Nominal rpm (N) 1440 rpm
Electric supply (U)   1×230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 1.4 A
Max. absorbed power (P1)**  0.23 kW
Motor output (P2)** 0.18 kW

Other data
Weight 23 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data for for t = 20°C
  • Density = 1.2 /m3
  • Values are based on the use of a transition piece equivalent to OGSR
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
BESF200 Box Ventilator
Call for price
BESF200 Box Ventilator Image

BESF200-4-1EC

Technical Data

MODEL BESF200-4-1EC
Fan data
Max. overall efficiency 48,6 %
ECO measurement set-up (A-D)  D
Efficiency requirements 49, N(2015)
ECO efficiency at optimal operating point 64,7

Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
156 W
912 m3/h
299 Pa
1427 rpm
Nominal rpm (N) 1435 rpm
Electric supply (U)   1×230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 2.6 A
Max. absorbed power (P1)**  0.43 kW
Motor output (P2)** 0,37 kW

Other data
Weight 23 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data for for t = 20°C
  • Density = 1.2 /m3
  • Values are based on the use of a transition piece equivalent to OGSR
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40° C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
BESF225 Box Ventilator
Call for price
BESF225 Box Ventilator Image

BESF225-4-1EC

Technical Data

MODEL BESF225-4-1EC
Fan data
Max. overall efficiency 53,9 %
ECO measurement set-up (A-D)  D
Efficiency requirements 49, N(2015)
ECO efficiency at optimal operating point 68,7

Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
235 W
1112 m3/h
410 Pa
1448 rpm
Nominal rpm (N) 1420 rpm
Electric supply (U)   1 x 230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 5.0 A
Max. absorbed power (P1)**  0.80 kW
Motor output (P2)** 0.75 kW

Other data
Weight 32 kg

Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data for for t = 20°C
  • Density = 1.2 /m3
  • Values are based on the use of a transition piece equivalent to OGSR
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40° C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
BESF250 Box Ventilator
Call for price
BESF250 Box Ventilator Image

BESF250-4-1EC

Technical Data

MODEL BESF250-4-1EC
Fan data
Max. overall efficiency 53,5 %
ECO measurement set-up (A-D)  D
Efficiency requirements 49, N(2015)
ECO efficiency at optimal operating point 66,9
Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
357 W
1390 m3/h
495 Pa
1433 rpm
Nominal rpm (N) 1420 rpm
Electric supply (U)   1 x 230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 8.5 A
Max. absorbed power (P1)**  1.32 kW
Motor output (P2)**  1.10 kW
Other data
Weight 32 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data for for t = 20°C
  • Density = 1.2 /m3
  • Values are based on the use of a transition piece equivalent to OGSR
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions

BESF250-4-3

Technical Data

MODEL BESF250-4-3 OGSR
Fan data
Max. overall efficiency 42,9 %
ECO measurement set-up (A-D) D
Efficiency requirements  49 N2015)
ECO efficiency at optimal operating point 50,7
Motor
Motor Three-phase motor designed for 1400 rpm or for an external frequency converter
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
585 W
1600 m3/h
564 Pa
1476 rpm
 Nominal rpm 1400
Electric supply (U) 3x230D/400Y
Overload protection Must be overload-protected in accordance with applicable regulations
Max absorbed current* (I) 5.0/2.9A
Max. absorbed power (P1)** 1.47 kW
Motor output (P2)** 1.10 kW

Supply
Supply (power cable) No supply
Supply (control cable)
Length

Other data
Weight 48 kg
BESF280 Box Ventilator
Call for price
BESF280 Box Ventilator Image

BESF280-4-3 and BESF280-4-3EC

Technical Data

MODEL  BESF280-4-3 OGSR BESF280-4-3EC OGSR
Fan data
Max. overall efficiency 52,6 % 58,5 %
ECO measurement set-up (A-D)  D  D
Efficiency requirements 49, N(2015) 49, N(2015)
ECO efficiency at optimal operating point 59,1 68,9

Motor
Motor Three-phase motor designed for 1400 rpm or for an external frequency converter EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
955 W
2354 m3/h
769 Pa
1481 rpm
493 W
1870 m3/h
555 Pa
1306 rpm
Nominal rpm (N)  1400 rpm 1448 rpm
Electric supply (U)   3 x 230D/400Y
Overload protection Must be overload-protected in accordance with applicable regulations Integrated in motor control
Max absorbed current* (I) 7,15 A 5.3 A
Max. absorbed power (P1)**  2.9 kW 3.2 kW
Motor output (P2)** 2,2 kW 2.2 kW

Other data
Weight 57 kg 65 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data for for t = 20°C
  • Density = 1.2 /m3
  • Values are based on the use of a transition piece equivalent to OGSR
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
Butterfly Cap-Damper
Call for price
Butterfly Cap-Damper Image

Butterfly Cap-Damper

LIFETIME GUARANTEE!

Just like the Butterfly damper, the Butterfly Cap-Damper gives you access to the chimney with the removal of a couple of wingnuts (below). Because of its design, the Butterfly Cap-Damper installs on either a chimney with a flue tile (liner) sticking up or one that does not have a tile above the crown. Just glue it on with the silicone that comes with it!

Constructed of 304 stainless steel, spring loaded, it’s simple for your customer to use and easy to install (just silicone it on).

Each damper comes with 32’ of SS cable. 3’ of SS cable guard for the offset of the flu, 10 oz. tube of silicone, firebox bracket pack; all you need are tools.

Huge heat loss occurs when a chimney damper doesn’t seal properly or is missing or broken. A new top-sealing damper will normally pay for itself the first year from the savings on the heating bill alone.



Butterfly Damper
Call for price
Butterfly Damper Image

Butterfly Damper

Lifetime Guarantee

Chimney Products Inc. top-sealing Butterfly Damper is great for those chimneys that don’t have a raised flue liner, under Multi-Flue chimney caps, or as a low profile stand-alone damper.

Constructed of 304 stainless steel, spring loaded, it’s simple for your customer to use and easy to install (just silicone it on).

Each damper comes with 32’ of SS cable. 3’ of SS cable guard for the offset of the flu, 10 oz. tube of silicone, firebox bracket pack; all you need are tools.

Huge heat loss occurs when a chimney damper doesn’t seal properly or is missing or broken. A new top-sealing damper will normally pay for itself the first yearfrom the savings on the heating bill alone.

California Universal Chimney Cap - Black Galvanized - 5/8
Call for price
California Universal Chimney Cap - Black Galvanized - 5/8 Image

California Universal Chimney Cap – Black Galvanized – 5/8″ Mesh

California Universal Chimney Cap
Black Galvanized – 5/8″ Mesh

The “101”, “Premie”, “Galvie”, “The Black One”, “The one I always order”, yep this is the one. Fits 95% of masonry chimneys in California! Fits every California oval! Chimney sweeps, stove stores and masonry contractors have installed more than 300,000 of them over the last 19 years, so I guess they work. Comes with a 6 year guarantee, no tools to install and real friendly! Black power coated, with 24 gauge stamped lid (with a little chimney sweep on it), 18 gauge expanded metal-diamond mesh in 5/8” California code. Also available in ¾ mesh.

Ships in either a single box or the compact, economical 4-pack.

Held on by an inside mounted anchor, so it works even when the chimney doesn’t have a raised flue line.

Of course, there is a Universal Dampener Kit for the California Universal Chimney Cap. Anything the cap fits (95%), so will the damper.



California Universal Chimney Cap - Copper - 5/8
Call for price
California Universal Chimney Cap - Copper - 5/8 Image

California Universal Chimney Cap – Copper – 5/8″ Mesh

Size – 13×20.5
Lifetime Guarantee!

California Universal Chimney Cap in Copper! For those folks who want the top of the line, you can’t beat copper. Over time these copper caps patina get that “antiqued” look that is so popular.

The Universal Copper Cap’s mesh and hardware are copper clad 304 Stainless Steel, the anchor is stainless, and the top is all copper.

The Universal Copper Cap comes with a Lifetime Guarantee. There is nothing finer on the market!

Ships in either a single box or economical 4-pack just like the 101. When folks want a LIFETIME of trouble free service, this is the one to recommend.

Held on by an inside mounted anchor, so it works even when the chimney doesn’t have a raised flue line.

And of course, there is a Universal Dampener Kit for the California Universal Chimney Cap. This combination makes an all stainless steel cap-damper.



California Universal Chimney Cap - Stainless Steel - 5/8
Call for price
California Universal Chimney Cap - Stainless Steel - 5/8 Image

California Universal Chimney Cap
Stainless Steel – 5/8″ Mesh

Exactly the same chimney cap as Chimney Products “101” only constructed of 304 Stainless Steel with a Lifetime Guarantee! In California this chimney cap is recommended for anyone who lives within 20 miles of the coast (salt eats other metals) or in high altitude conditions (above 5000 ft.)

Also available in 3/4″ mesh!!

Ships in either a single box or economical 4-pack just like the 101. When folks want a LIFETIME of trouble free service, this is the one to recommend.

Held on by an inside mounted anchor, so it works even when the chimney doesn’t have a raised flue line.

And of course, there is a Universal Dampener Kit for the California Universal Chimney Cap. This combination makes an all stainless steel cap-damper.



California Universal Chimney Cap-Black Stainless Steel - 5/8
Call for price
California Universal Chimney Cap-Black Stainless Steel - 5/8 Image

California Universal Chimney Cap
Black Stainless Steel – 5/8″ Mesh
Size 13×20.5

Called the Black Beauty, exactly the same chimney cap as the “101” only constructed of 304 Stainless Steel with a Lifetime Guarantee! In California this chimney cap is recommended for anyone who lives within 20 miles of the coast (salt eats other metals) or in high altitude conditions (above 5000 ft.).

Held on by an inside mounted anchor, so it works even when the chimney doesn’t have a raised flue line.

Of course, there is a Universal Dampener Kit for the California Universal Chimney Cap. Anything the cap fits (95%), so will the damper.



California Universal Specialty Cap - Black - 5/8
Call for price
California Universal Specialty Cap - Black - 5/8 Image

California Universal Specialty Cap – Black – 5/8″ Mesh

Because the California Universal only fits about 95% of masonry chimneys in California, Chimney Products has some caps to fit the remaining 5%. the most popular (most used) is the 13″x13″ which fits down to 8″x8″ and everything in between (like 9″, 10″, 12″ and 13″ masonry rounds). They are constructed with the same quality materials as the California Universal with 5/8″ mesh, and installs the same way.

The packing is a little different because of their size–you can get them shipped in either a single or 5-Pack. Great for the S.F. Bay Area’s patent chimneys and those concrete “tilt-ups”.



California Universal Specialty Cap - Copper - 5/8
Call for price
California Universal Specialty Cap - Copper - 5/8 Image

California Universal Specialty Cap – Copper – 5/8″ Mesh



Size 13×13

Because the California Universal only fits about 95% of masonry chimneys in California, Chimney Products has some caps to fit the remaining 5%. the most popular (most used) is the 13″x13″ which fits down to 8″x8″ and everything in between (like 9″, 10″, 12″ and 13″ masonry rounds). They are constructed with the same quality materials as the California Universal with 5/8″ mesh, and installs the same way.

California Universal Chimney Cap in Copper! For those folks who want the top of the line, you can’t beat copper. Over time these copper caps patina get that “antiqued” look that is so popular.

The packing is a little different because of their size–you can get them shipped in either a single or 5-Pack. Great for the S.F. Bay Area’s patent chimneys and those concrete “tilt-ups”.



California Universal Specialty Cap - Stainless Steel - 5/8
Call for price
California Universal Specialty Cap - Stainless Steel - 5/8 Image

California Universal Specialty Cap – Stainless Steel – 5/8″ Mesh



Because the California Universal only fits about 95% of masonry chimneys in California, Chimney Products has some caps to fit the remaining 5%. the most popular (most used) is the 13″x13″ which fits down to 8″x8″ and everything in between (like 9″, 10″, 12″ and 13″ masonry rounds). They are constructed with the same quality materials as the California Universal with 5/8″ mesh, and installs the same way.

The packing is a little different because of their size–you can get them shipped in either a single or 5-Pack. Great for the S.F. Bay Area’s patent chimneys and those concrete “tilt-ups”.



Chimney Liners
Call for price
Copper Outside Mount Cap
Copper Pot Toppers
Call for price
Copper Pot Toppers
Call for price
Cover 2 Stock Copper
Covers Caperose
Call for price
Covers Chase Custom
Covers Edinburgh
Call for price
Covers Luxemburg
Call for price
Covers Provincial
Call for price
Covers Rockport
Call for price
Covers Roman
Call for price
Covers Tudor
Call for price
Covers Turretfin
Call for price
Covers Tuscan
Call for price
Covers Wellington
Call for price
Covers Windsor
Call for price
Custom Copper Corner
Call for price
Custom Copper Gable
Call for price
Custom Copper Hip
Call for price
Custom Copper Lid
Call for price
Custom Copper R400
Call for price
Custom Copper TD400
Call for price
Custom Traditional Hood
Call for price
Drop-In Damper - 304 Stainless Steel
Call for price
Drop-In Damper - 304 Stainless Steel Image

Drop-In Damper – 304 Stainless Steel

Drop-In Damper – 304 Stainless Steel

The all 304 Stainless Steel DROP-IN DAMPERS can be used with most existing chimney caps.

Just remove the cap, drop in the damper or slide the legs of the Drop-In Damper into the cap, and put it in the flue.

Constructed of 14-gauge 304 stainless steel with a special frost breaking feature. It is easy to install and simple for the customer to operate.

Comes with a LIFETIME GUARANTEE, and uses our standard cable and handle assembly. Uses a counter-weight principle to open the damper plate.

DTH 160 Roof Fan Horizontal Exhaust
Call for price
DTH 160 Roof Fan Horizontal Exhaust Image

DTH160

Technical Data

MODEL DTH160-4-1
Motor
Motor Single-phase motor
Nominal rpm (N)  1400 rpm at 50 Hz
Electric supply (U)  1×230 V
Overload protection  Integral thermal cutout (TP211) in motor power circuit
Max absorbed current* (I)  0.14 A.
Max. absorbed power (P1)**  0.04 kW
Motor output (P2)**  0.01 kW

Supply
Supply (power cable) 3 x 0.75  mm2
Length 0.8 m

Other data
Weight 9 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
DTH Roof Fan Horizontal Exhaust
Call for price
DTH Roof Fan Horizontal Exhaust Image

DTH Overview



Capacity m3/h
Min. Max.
DTH160-4-1 60 370
DTH200-4-1 120 800
DTH250-4-1EC 250 1,740
DTH315-4-1EC 450 3,250
DTH400-4-1EC 660 4,900

Design

DTH is made from cast aluminium, giving it a high corrosion resistance. It is painted in black RAL 7021, a suitable colour for most roofs.

Horizontal Exhaust

DTH is an extract fan with a horizontal exhaust.

The design ensures an optimum air handling solution with minimum noise.

Fan Impeller

DTH roof fan is ideal for ventilation tasks requiring efficient and economical ventilation.

The specially developed centrifugal impeller with backward curved blades ensures high efficiency and low operating costs.

Service

DTH roof fan is easy to open for cleaning and maintenance.

Motor Types

DTH roof fan

DTH is available with 2 motor types:

  • Single-phase voltage controlled motor
  • EC motor

The motors are made to protection class IP54 and all materials are as a minimum class F (155 °C). The motor  has integral current overload protection.


EC motor

The EC motor is a highly efficient permanent-magnet motor of class IE5 with motor control for a 1 x 230 V connection. The motor control has been specially developed for compatibility with the EXHAUSTO DTV roof fan and, when used with this motor, ensures the lowest possible operating costs.

The motor control protects the motor from overloading, blocking, over and under voltage, and over heating. It is factory programmed by EXHAUSTO for optimal operation of the fan. It only has to be connected to a 1 X 230 VAC supply and to an EXHAUSTO EFC1P or MAC12 controller.

The motor controls also provide a Modbus interface for fan control and alarm read-offs etc.


Single-phase motor

Single-phase motors can be selected for the 2 smallest DTH models. All motors are 4-pole with 1400 rpm, and permit direct voltage control using EXHAUSTO EFC16, EFC35 and MAC12 controllers (with MPR4/MPR8 module).





DTH200 Roof Fan Horizontal Exhaust
Call for price
DTH200 Roof Fan Horizontal Exhaust Image

DTH200

Technical Data

MODEL DTH200-4-1
Motor
Motor Single-phase motor
Nominal rpm (N)  1400 rpm at 50 Hz
Electric supply (U)  1×230 V
Overload protection  Integral thermal cutout (TP211) in motor power circuit
Max absorbed current* (I)  0.35 A.
Max. absorbed power (P1)**  0.07 kW
Motor output (P2)**  0.04 kW

Supply
Supply (power cable) 3 x 0.75  mm2
Length 1.05 m

Other data
Weight 13 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
DTH250 Roof Fan Horizontal Exhaust
Call for price
DTH250 Roof Fan Horizontal Exhaust Image

DTH250

Technical Data

The motor controller for the EC motor is supplied in a black box for fixing to the roof vent.

NB: Due to EMC requirements the cable between the EC control and the EC motor must not be elongated.
MODEL DTH250-4-1EC
Fan data
Max. overall efficiency 48,8 %
ECO measurement set-up (A-D)  C
Efficiency requirements 62, N(2015)
ECO efficiency at optimal operating point 72,4

Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
181 W
1271 m3/h
250 Pa
1635 rpm
Nominal rpm (N) 1635 rpm
Electric supply (U)   1 x 230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 1.2 A
Max. absorbed power (P1)**  0.19 kW
Motor output (P2)** 0,18 kW
Supply
Supply (power cable)  –
Length  –

Other data
Weight 21 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
DTH315 Roof Fan Horizontal Exhaust
Call for price
DTH315 Roof Fan Horizontal Exhaust Image

DTH315

Technical Data

The motor controller for the EC motor is supplied in a black box for fixing to the roof vent.

NB: Due to EMC requirements the cable between the EC control and the EC motor must not be elongated.
MODEL DTH315-4-1EC
Fan data
Max. overall efficiency 50,9 %
ECO measurement set-up (A-D)  C
Efficiency requirements 62, N(2015)
ECO efficiency at optimal operating point 71,8

Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
310 W
2160 m3/h
263 Pa
1446 rpm
Nominal rpm (N) 1605 rpm
Electric supply (U)   1 x 230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 2,6 A
Max. absorbed power (P1)**  0.46 kW
Motor output (P2)** 0,37 kW
Supply
Supply (power cable)  –
Length  –

Other data
Weight 29 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
DTH400 Roof Fan Horizontal Exhaust
Call for price
DTH400 Roof Fan Horizontal Exhaust Image

DTH400

Technical Data

The motor controller for the EC motor is supplied in a black box for fixing to the roof vent.

NB: Due to EMC requirements the cable between the EC control and the EC motor must not be elongated.
MODEL DTH400-4-1EC
Fan data
Max. overall efficiency 54,8 %
ECO measurement set-up (A-D) C
Efficiency requirements  62, N(2015)
ECO efficiency at optimal operating point 71,6

Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
677 W
3127 m3/h
427 Pa
1520 rpm
Nominal rpm (N) 1538
Electric supply (U)   1×230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 4.5 A
Max. absorbed power (P1)** 0.72 kW
Motor output (P2)** 0,75 kW

Other data
Weight 40 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
DTV 160 Roof Fan Vertical Exhaust
Call for price
DTV 160 Roof Fan Vertical Exhaust Image

DTV160

Technical Data

MODEL DTV160-4-1
Motor
Motor Single-phase motor
Nominal rpm (N)  1400 rpm at 50 Hz
Electric supply (U)  1×230 V
Overload protection  Integral thermal cutout (TP211) in motor power circuit
Max absorbed current* (I)  0.14 A.
Max. absorbed power (P1)**  0.04 kW
Motor output (P2)**  0.01 kW

Supply
Supply (power cable) 3 x 0.75  mm2
Length 0.8 m

Other data
Weight  11 kg.



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
DTV Roof Fan Vertical Exhaust
Call for price
DTV Roof Fan Vertical Exhaust Image

DTV Overview



Capacity m3/h
Min. Max.
DTV160-4-1 60 320
DTV200-4-1 120 680
DTV250-4-1EC 300 1,780
DTV315-4-1EC 450 2,950
DTV400-4-1EC 700 5,000
DTV450-4-1EC 1,050 6,300

Design

DTV Roof Fan

DTV is made from cast aluminium, giving it a high corrosion resistance. It is painted in black RAL 7021, a suitable colour for most roofs.

Vertical Exhaust

DTV roof fan is an extract fan with vertical exhaust.

This prevents soiling of the roof and the downdraught of polluted air. It is also less noisy.

Fan Impeller

DTV roof fan is ideal for ventilation tasks requiring efficient and economical ventilation.

The specially developed centrifugal impeller with backward curved blades ensures high efficiency and low operating costs.

Service

DTV roof fan is easy to open for cleaning and maintenance.





Motor Types

DTV roof fan

The motor on the DTV is connected directly to the centrifugal impeller, but lies outside the airflow.

DTV roof fan is available with two alternative motors:

  • EC motor
  • single-phase voltage controlled motor

The motors are made to protection class IP54 and all materials are as a minimum class F (155 °C).  All motor types have integral current overload protection.


EC motor

The EC motor is a highly efficient permanent-magnet motor of class IE5 with motor control for a 1 x 230 V connection. The motor control has been specially developed for compatibility with the EXHAUSTO DTV roof fan and, when used with this motor, ensures the lowest possible operating costs.
The motor control protects the motor from overloading, blocking, over and under voltage, and over heating. It is factory programmed by EXHAUSTO for optimal operation of the fan. It only has to be connected to a 1 X 230 VAC supply and to an EXHAUSTO EFC1P or MAC12 controller.
The motor controls also provide a Modbus interface for fan control and alarm read-offs etc.


Single-phase motor:

Single-phase motors can be selected for the 2 smallest DTV models. All motors are 4-pole with 1400 rpm and permit direct voltage control using EXHAUSTO controllers EFC15, EFC35 and MAC12 (with MPR4/MPR8 module).

DTV200 Roof Fan Vertical Exhaust
Call for price
DTV200 Roof Fan Vertical Exhaust Image

DTV200

Technical Data

MODEL DTV200-4-1
Motor
Motor Single-phase motor
Nominal rpm (N)  1400 rpm at 50 Hz
Electric supply (U)  1×230 V
Overload protection  Integral thermal cutout (TP211) in motor power circuit
Max absorbed current* (I)  0.35 A.
Max. absorbed power (P1)**  0.07 kW
Motor output (P2)**  0.04 kW
Supply
Supply (power cable) 3 x 0.75  mm2
Length 0.8 m
Other data
Weight  17 kg.



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
DTV250 Roof Fan Vertical Exhaust
Call for price
DTV250 Roof Fan Vertical Exhaust Image

DTV250-4-1EC

Technical Data

MODEL DTV250-4-1EC
Fan data
Max. overall efficiency 51,9 %
ECO measurement set-up (A-D)  C
Efficiency requirements 62, N(2015)
ECO efficiency at optimal operating point 76,2
Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
159 W
1111 m3/h
268 Pa
1635 rpm
Nominal rpm (N) 1635 rpm
Electric supply (U)   1 x 230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 1.2 A
Max. absorbed power (P1)**  0.11 kW
Motor output (P2)** 0,16 kW
Supply
Supply (power cable)  –
Length  –
Other data
Weight 28 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40° C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions

DTV250-4-1FC

Technical Data

MODEL  DTV250-4-1FC
Fan data
Max. overall efficiency 42,4 %
ECO measurement set-up (A-D) C
Efficiency requirements 62 N(2015)
ECO efficiency at optimal operating point 65,5
Motor
Motor FC motor with integrated motor control
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
203 W
1144 m3/h
271 Pa
1640 rpm
 Nominal rpm 1626 rpm
Electric supply (U)  1 x 230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 1.4 A
Max. absorbed power (P1)** 0.21 kW
Motor output (P2)** 0.18 kW

Supply
Supply (power cable) 3 x 0.75 mm2
Supply (control cable) 7 x 0.34 mm2
Length 1.60 m

Other data
Weight 25 kg
DTV315 Roof Fan Vertical Exhaust
Call for price
DTV315 Roof Fan Vertical Exhaust Image

DTV315-4-1EC

Technical Data

MODEL DTV315-4-1EC
Fan data
Max. overall efficiency 52,4 %
ECO measurement set-up (A-D)  C
Efficiency requirements 62, N(2015)
ECO efficiency at optimal operating point 73,1
Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
318 W
1779 m3/h
337 Pa
1517 rpm
Nominal rpm (N) 1605 rpm
Electric supply (U)   1 x 230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 2,4 A
Max. absorbed power (P1)**  0.39 kW
Motor output (P2)** 0,37 kW
Supply
Supply (power cable)  –
Length  –
Other data
Weight 37 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40° C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
DTV400 Roof Fan Vertical Exhaust
Call for price
DTV400 Roof Fan Vertical Exhaust Image

DTV400

Tehcnical Data

MODEL DTV400-4-1EC
Fan data
Max. overall efficiency 53,4 %
ECO measurement set-up (A-D) C
Efficiency requirements  62, N(2015)
ECO efficiency at optimal operating point 68,3

Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
954 W
2804 m3/h
654 Pa
1829 rpm
Nominal rpm (N) 1820
Electric supply (U)   1×230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 7.5 A
Max. absorbed power (P1)** 1.04 kW
Motor output (P2)** 0,75 kW

Other data
Weight 52 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40°C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
DTV450 Roof Fan Vertical Exhaust
Call for price
DTV450 Roof Fan Vertical Exhaust Image

DTV450

Technical Data

MODEL DTV450-4-1EC
Fan data
Max. overall efficiency 57,1 %
ECO measurement set-up (A-D) C
Efficiency requirements  62, N(2015)
ECO efficiency at optimal operating point 73,3

Motor
Motor EC motor with integral VSD
Optimal operating point:
Absorbed power
Airflow
Total pressure
Rpm
763 W
2934  m3/h
535 Pa
1700 rpm
Nominal rpm (N) 1700
Electric supply (U)   1 x 230 V ~ 50 Hz
Overload protection Integrated in motor control
Max absorbed current* (I) 8.0 A
Max. absorbed power (P1)** 1.12 kW
Motor output (P2)** 1,1 kW

Other data
Weight 60 kg



Conditions:

  • * I is the maximum absorbed current throughout the control range – or the full load current if this is larger
  • ** P1 is the maximum absorbed power from the mains supply, where P2 is the motor’s nominal output.
  • Stated data are for t = 20°C
  • Density = 1.2 kg/m3
  • Gas temperature: min. -12°C, max. +60° C
  • Ambient temperature: Max. +40° C
  • Pressure ratio: < 1,11
  • other points in acc. with EC327/2011 – see product instructions
Gable Chimney Top
Call for price
Ice Breaker Chimney Cap-Damper - 3/4
Call for price
Ice Breaker Chimney Cap-Damper - 3/4 Image

The “Ice Breaker” Chimney Cap-Damper
3/4″ MESH SINGLE FLUE CAP-DAMPER

(LIFETIME GUARANTEE)

Chimney Product’s Lifetime Guarantee Cap-Damper. The same sturdy, reliable, rugged, and easy to install, all 304 stainless steel single flue chimney cap with a damper built in. Comes with 32 feet of stainless steel cable, 3 feet of stainless steel cable guard to protect the cable at the flue offset, and 10.5 oz. tube of XtraBond 250 silicone sealant.

Huge heat loss occurs when a chimney damper doesn’t seal properly or is missing or broken. A new to-sealing damper will normally pay for itself the first year from the savings on the heating bill alone.

Easy to install, all stainless steel top sealing damper. Doesn’t downsize the flue. Seals air tight and takes only 13 lbs of pull to open or close.

NOTE: Dimensions adjust to fit up to 1″ larger and 1.5″ smaller (2.5″ adjustment) like the Single Flue chimney cap!

4 or 10 of any mix of sizes qualifies you for the discounts!



Liner Inserts 320x200
Call for price
Modular Chimney Caps - Stainless Steel - 3/4
Call for price
Modular Chimney Caps - Stainless Steel - 3/4 Image

The Modular Chimney Cap Stainless Steel – 3/4″ Mesh, 12″ Screen Height

Modular: Composed of standardized units or sections for easy construction or flexible arrangement.

Tired of ordering custom caps? Tired of dealing with freight lines when you do order them? Tired of paying for the crating of them? Tired of the wait? Tired of the high cost to get them to you?

The Modular comes in a standard UPS’able box!! Choose the width you need. Four to choose from: 13.5″, 17″, 22″ or 28″ widths. Assembles and installs like our regular Multi-Flue Chimney Caps, just a two part lid!

Like our Multi-Flue Chimney Caps, the flange on the cage bottom is reversible. Need it smaller? No problem. Just overlap the side panels and lids. Need it longer? Just add as many center section extensions as you need.

The Modular chimney cap comes in widths of 13.5″, 17″, 22″ or 28″ with 12″ screen height, in either stainless steel or copper, and you make it as long as you need!!

Also available to order: Stainless Let Kits (4), Stainless Corners (4), and Stainless Keyhole Anchors (4 Anchors + 4 Tapcons)





Modular Chimney Caps - Stainless Steel - California 5/8
Call for price
Modular Chimney Caps - Stainless Steel - California 5/8 Image

The Modular Chimney Cap Stainless Steel – California 5/8″ Mesh, 10″ Screen Height

Modular: Composed of standardized units or sections for easy construction or flexible arrangement.

Tired of ordering custom caps? Tired of dealing with freight lines when you do order them? Tired of paying for the crating of them? Tired of the wait? Tired of the high cost to get them to you?

The Modular comes in a standard UPS’able box!! Choose the width you need. Four to choose from: 13.5″, 17″, 22″ or 28″ widths. Assembles and installs like our regular Multi-Flue Chimney Caps, just a two part lid!

Like our Multi-Flue Chimney Caps, the flange on the cage bottom is reversible. Need it smaller? No problem. Just overlap the side panels and lids. Need it longer? Just add as many center section extensions as you need.

The Modular chimney cap comes in widths of 13.5″, 17″, 22″ or 28″ with 12″ screen height, in either stainless steel or copper, and you make it as long as you need!!

Also available to order: Stainless Let Kits (4), Stainless Corners (4), and Stainless Keyhole Anchors (4 Anchors + 4 Tapcons)



Modular Extensions for Stainless Steel Modular Chimney Caps - 3/4
Call for price
Modular Extensions for Stainless Steel Modular Chimney Caps - 3/4 Image

Modular Extensions  for Stainless Steel Modular Chimney Caps – 3/4″ Mesh

Modular: Composed of standardized units or sections for easy construction or flexible arrangement.

With the Modular Chimney Caps you choose the width you need. Need it smaller? No problem. Just overlap the side panels and lids. Need it longer? Just add as many center section extensions as you need.

Modular Extensions for Stainless Steel Modular Chimney Caps - CA 5/8
Call for price
Modular Extensions for Stainless Steel Modular Chimney Caps - CA 5/8 Image

Modular Extensions  for Stainless Steel
Modular Chimney Caps – California 5/8″ Mesh

Modular: Composed of standardized units or sections for easy construction or flexible arrangement.

With the Modular Chimney Caps you choose the width you need. Need it smaller? No problem. Just overlap the side panels and lids. Need it longer? Just add as many center section extensions as you need.



Monsoon Cap
Call for price
Monsoon Cap Image

Monsoon Cap

A replacement lid for our standard chimney cap for metal chimneys that turns it into a
“Monsoon Cap” to keep out driving rain. Just change them out with the one wingnut on top.

The “Monsoon” cures most wind related down draft problems. Its design actually increases draft as the win speed increases. So if the smoking problem is wind related, the “Monsoon” and a Smoke Guard usually handles it.

Multi-Flue Chimney Caps - 304 Stainless Steel *Reversible* - 3/4
Call for price
Multi-Flue Chimney Caps - 304 Stainless Steel *Reversible* - 3/4 Image

Stainless Steel *Reversible* Multi-Flue Chimney Cap  3/4″ Mesh (Lifetime Guarantee) – 10″ Screen Height

All Chimney Products Multi-flue sizes have reversible panels for ease of installation, lids held on with studs and wingnuts for easy service, 10″ screen height, and come boxed in knock-down form to save on space and freight!

The anchoring flange at the base of the Multi-Flue chimney cap can face either in or out, on any side to give a great fit.

Note: Caps come with tapcons and silicone adhesive.

Baffles are available for both S.S. and Black caps. (Note: When covering two or more flues sometimes a “smoke over” problem occurs (smoke from one flue going down another). A baffle between the flues usually eliminates this when it does occur.)



Multi-Flue Chimney Caps - 304 Stainless Steel *Reversible* - CA 5/8
Call for price
Multi-Flue Chimney Caps - 304 Stainless Steel *Reversible* - CA 5/8 Image

Stainless Steel *Reversible* Multi-Flue Chimney Cap California 5/8″ Mesh (Lifetime Guarantee) with 10″ Screen Height

All Chimney Products Multi-flue sizes have reversible panels for ease of installation, lids held on with studs and wingnuts for easy service, 10″ screen height, and come boxed in knock-down form to save on space and freight!

The anchoring flange at the base of the Multi-Flue chimney cap can face either in or out, on any side to give a great fit.

Note: Caps come with tapcons and silicone adhesive.

Baffles are available for both S.S. and Black caps. (Note: When covering two or more flues sometimes a “smoke over” problem occurs (smoke from one flue going down another). A baffle between the flues usually eliminates this when it does occur.)



Multi-Flue Chimney Caps - Black *Reversible* - CA 5/8
Call for price
Multi-Flue Chimney Caps - Black *Reversible* - CA 5/8 Image

Black *Reversible* Multi-Flue Chimney Cap
California 5/8″ Mesh (6 Year Guarantee) – 10″ Screen Height

All Chimney Products Multi-flue sizes have reversible panels for ease of installation, lids held on with studs and wingnuts for easy service, 10″ screen height, and come boxed in knock-down form to save on space and freight!

The anchoring flange at the base of the Multi-Flue chimney cap can face either in or out, on any side to give a great fit.

Note: Caps come with tapcons and silicone adhesive.

Baffles are available for both S.S. and Black caps. (Note: When covering two or more flues sometimes a “smoke over” problem occurs (smoke from one flue going down another). A baffle between the flues usually eliminates this when it does occur.)

Multi-Flue Chimney Caps - Black Powder Coated *Reversible* - 3/4
Call for price
Multi-Flue Chimney Caps - Black Powder Coated *Reversible* - 3/4 Image

Premium Black Powder Coated *Reversible* Multi-Flue Chimney Cap
3/4″ Mesh (6 Year Guarantee) – 10″ Screen Height

All Chimney Products Multi-flue sizes have reversible panels for ease of installation, lids held on with studs and wingnuts for easy service, 10″ screen height, and come boxed in knock-down form to save on space and freight!

The anchoring flange at the base of the Multi-Flue chimney cap can face either in or out, on any side to give a great fit.

Note: Caps come with tapcons and silicone adhesive.

Baffles are available for both S.S. and Black caps. (Note: When covering two or more flues sometimes a “smoke over” problem occurs (smoke from one flue going down another). A baffle between the flues usually eliminates this when it does occur.)



Multi-Flue Chimney Caps - Copper *Reversible* - 3/4
Call for price
Multi-Flue Chimney Caps - Copper *Reversible* - 3/4 Image

Copper *Reversible* Multi-Flue Chimney Cap 3/4″ Mesh (Lifetime Guarantee) – 10″ Screen Height

All Chimney Products Multi-flue sizes have reversible panels for ease of installation, lids held on with studs and wingnuts for easy service, 10″ screen height, and come boxed in knock-down form to save on space and freight!

The anchoring flange at the base of the Multi-Flue chimney cap can face either in or out, on any side to give a great fit.

Copper is the top-of-the-line. As the copper ages it gives that unique antique look (patina). Both Stackable Solid Frame chimney caps and Multi-Flue chimney caps have solid copper tops with copper clad (plated) stainless steel hardware, base and screen. They both come with a Lifetime Guarantee.

Note: Patina may stain lighter colored chimneys.

Note: Caps come with tapcons and silicone adhesive for mounting.

Multi-Flue Chimney Caps - Copper *Reversible* - CA 5/8
Call for price
Multi-Flue Chimney Caps - Copper *Reversible* - CA 5/8 Image

Copper *Reversible* Multi-Flue Chimney Cap California 5/8″ Mesh (Lifetime Guarantee) with 10″ Screen Height

All Chimney Products Multi-flue sizes have reversible panels for ease of installation, lids held on with studs and wingnuts for easy service, 10″ screen height, and come boxed in knock-down form to save on space and freight!

The anchoring flange at the base of the Multi-Flue chimney cap can face either in or out, on any side to give a great fit.

Copper is the top-of-the-line. As the copper ages it gives that unique antique look (patina). Both Stackable Solid Frame chimney caps and Multi-Flue chimney caps have solid copper tops with copper clad (plated) stainless steel hardware, base and screen. They both come with a Lifetime Guarantee.

Note: Patina may stain lighter colored chimneys.

Note: Caps come with tapcons and silicone adhesive for mounting.

Pots Caperose
Call for price
Pots Edinburgh
Call for price
Pots Luxemburg
Call for price
Pots Provincial
Call for price
Pots Rockport
Call for price
Pots Roman
Call for price
Pots Toppers
Call for price
Pots Tudor
Call for price
Pots Turretfin
Call for price
Pots Tuscan
Call for price
Pots Wellington
Call for price
Pots Windsor
Call for price
Rockport
Call for price
Round Cap Damper Air Insulated 1/2
Call for price
Round Cap Damper Air Insulated 1/2 Image

Round Cap Damper Air Insulated 1/2″ Mesh

The Round Ice Breaker is just as rugged and reliable as it’s square counterpart. It is made of all 304 stainless steel. We tested it by freezing it well below freezing temperatures and it opened every time, no problem.



Round Cap Damper Air Insulated 1/2
Call for price
Round Cap Damper Air Insulated 1/2 Image

Round Cap Damper Air Insulated 1/2″ Mesh

The Round Ice Breaker is just as rugged and reliable as it’s square counterpart. It is made of all 304 stainless steel. We tested it by freezing it well below freezing temperatures and it opened every time, no problem.
Round Cap Damper Solid Pack 1
Call for price
Round Cap Damper Solid Pack 1 Image

Round Cap Damper Solid Pack 1″ Mesh

The Round Ice Breaker is just as rugged and reliable as it’s square counterpart. It is made of all 304 stainless steel. We tested it by freezing it well below freezing temperatures and it opened every time, no problem.
Round Cap Damper Solid Pack 1
Call for price
Round Cap Damper Solid Pack 1 Image

Round Cap Damper Solid Pack 1″ Mesh

The Round Ice Breaker is just as rugged and reliable as it’s square counterpart. It is made of all 304 stainless steel. We tested it by freezing it well below freezing temperatures and it opened every time, no problem.
Round Cap Damper Solid Pack 1/2
Call for price
Round Cap Damper Solid Pack 1/2 Image

Round Cap Damper Solid Pack 1/2″ Mesh

The Round Ice Breaker is just as rugged and reliable as it’s square counterpart. It is made of all 304 stainless steel. We tested it by freezing it well below freezing temperatures and it opened every time, no problem.
Round Ice Breaker Air Insulated 1
Call for price
Round Ice Breaker Air Insulated 1 Image

Round Ice Breaker Air Insulated 1″ Mesh

The Round Ice Breaker is just as rugged and reliable as it’s square counterpart. It is made of all 304 stainless steel. We tested it by freezing it well below freezing temperatures and it opened every time, no problem.





Single Flue Chimney Cap for Oval or Rectangular Flues - 304 Stainless Steel - CA 5/8
Call for price
Single Flue Chimney Cap for Oval or Rectangular Flues - 304 Stainless Steel - CA 5/8 Image

Single Flue Chimney Cap for Oval or Rectangular Flues  304 Stainless Steel – California 5/8″ Mesh

Designed for California. Made with special 5/8″ mesh just for California’s spark arrester code.

Solid, rugged and easy to install. You can feel confident your customer will appreciate you using the highest quality chimney cap that will give a lifetime of trouble free service!



Lid removes for easy servicing.

All Chimney Products Single Flue Chimney Caps for California come with removal corners so you get a perfect fit on all California ovals and no downsizing on rectangular flues.

Comes in either single, 2-pack, or 4-pack. Saving money and space, the 4-pack is ideal for the Chimney Professional!



Single Flue Chimney Cap for Oval or Rectangular Flues - Black - CA 5/8
Call for price
Single Flue Chimney Cap for Oval or Rectangular Flues - Black - CA 5/8 Image

Single Flue Chimney Cap for Oval or Rectangular Flues Black Galvanized (6 Year Guarantee) – California 5/8″ Mesh

Same popular design, just different material

Designed for California. Made with special 5/8″ mesh just for California’s spark arrester code.

Solid and dependable with 24-gauge stamped lid, 18-gauge expanded metal mesh, and 18-gauge frame. All backed by the best guarantee in the industry!

Lid removes for easy servicing.

All California 5/8″ mesh chimney caps come with slip corners for a perfect fit on ovals and no downsizing on rectangular flues.

Comes in either single, 2-pack, or 4-pack. The 4-pack saves space and money.

Single Wall/Solid-Pack Replacement Cap for Metal Chimneys - 1
Call for price
Single Wall/Solid-Pack Replacement Cap for Metal Chimneys - 1 Image

Single Wall/Solid-Pack Replacement Cap for Metal Chimneys 1″ Mesh for Outside California

This is the replacement cap for single wall or solid-pack metal chimney systems. These Chimney caps have a tight, friction-fit which we recommend you help along with a little silicone to keep it there.

Note: To get the correct size, measure the inside diameter of the center pipe. You must use the correct cap for each system. Using a single wall cap on an air-insulated chimney can cause it to over heat.

Single Wall/Solid-Pack Replacement Cap for Metal Chimneys - CA 1/2
Call for price
Single Wall/Solid-Pack Replacement Cap for Metal Chimneys - CA 1/2 Image

Single Wall/Solid-Pack Replacement Cap for Metal Chimneys – CA 1/2″ Mesh

Single Wall/Solid-Pack Replacement Cap for Metal Chimneys
California 1/2″ Mesh

This is the replacement cap for single wall or solid-pack metal chimney systems. These Chimney caps have a tight, friction-fit which we recommend you help along with a little silicone to keep it there.

Note: To get the correct size, measure the inside diameter of the center pipe.You must use the correct cap for each system. Using a single wall cap on an air-insulated chimney can cause it to over heat.





Solid Frame Chimney Cap - 304 Stainless Steel - Stackable 3/4
Call for price
Solid Frame Chimney Cap - 304 Stainless Steel - Stackable 3/4 Image

304 Stainless Steel Solid Frame Chimney Cap Stackable 3/4″ Mesh (Lifetime Guarantee)

Solid, reliable heavy-duty all 304 stainless steel, 24-gauge stamped lid, 18-gauge expanded metal mesh, and 18-gauge roll formed base. Comes in either single, 2-Pack or 4-Packs for economical shipping and storage. Guaranteed for a lifetime of trouble free service!

Note: Dimensions adjust to fit up to 1″ larger and 1.5″ smaller (2.5″ adjustment).

Note: Sizes 8×21 (SKU 368) and 8×27 (SKU 369) are not stackable; they come in singles only.

Solid Frame Chimney Cap - Black Powder Coated - Stackable 3/4
Call for price
Solid Frame Chimney Cap - Black Powder Coated - Stackable 3/4 Image

Black Powder Coated Solid Frame Chimney Cap Stackable 3/4″ Mesh (6 Year Guarantee)

The same solid, reliable, heavy-duty chimney cap as our 304 Stainless Steel only in a more economical material. Comes in either single, 2-Pack or 4-Packs for economical shipping and storage.

Note: Dimensions adjust to fit up to 1″ larger and 1.5″ smaller (2.5″ adjustment).

Solid Frame Chimney Cap - Copper - 3/4
Call for price
Solid Frame Chimney Cap - Copper - 3/4 Image

Copper Solid Frame Chimney Cap Stackable 3/4″ Mesh (Lifetime Guarantee)

Copper is the top-of-the-line. As the copper ages it gives that unique antique look (patina). Both Stackable Solid Frame chimney caps and Multi-Flue chimney caps have solid copper tops with copper clad (plated) stainless steel hardware, base and screen. They both come with a Lifetime Guarantee.

Note: Patina may stain lighter colored chimneys.

Note: Dimensions adjust to fit up to 1″ larger and 1.5″ smaller (2.5″ adjustment).

Stackable Round Single Flue Chimney Caps for Masonry Chimneys - 304 Stainless Steel - 3/4
Call for price
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - 304 Stainless Steel - 3/4 Image

Stackable Round Single Flue Chimney Caps for Masonry Chimneys 304 Stainless Steel (Lifetime Guarantee) – 3/4″ Mesh

Once in a while you run into a round flue liner in a masonry chimney. Generally this is handled with one of the Universal Caps, but sometimes your customers prefer a round cap on a round flue, so we offer 3 sizes in both Stainless Steel and Black Powder Coated.



Stackable Round Single Flue Chimney Caps for Masonry Chimneys - 304 Stainless Steel - CA 5/8
Call for price
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - 304 Stainless Steel - CA 5/8 Image

Stackable Round Single Flue Chimney Caps for Masonry Chimneys

304 Stainless Steel (Lifetime Guarantee) – California 5/8″ Mesh

Once in a while you run into a round flue liner in a masonry chimney. Generally this is handled with one of the Universal Caps, but sometimes your customers prefer a round cap on a round flue, so we offer 3 sizes in both Stainless Steel and Black Powder Coated.



Stackable Round Single Flue Chimney Caps for Masonry Chimneys - Black Powder Coated - 3/4
Call for price
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - Black Powder Coated - 3/4 Image

Stackable Round Single Flue Chimney Caps for Masonry Chimneys Black Powder Coated – 3/4″ Mesh (6 Year Guarantee)

Once in a while you run into a round flue liner in a masonry chimney. Generally this is handled with one of the Universal Caps, but sometimes your customers prefer a round cap on a round flue, so we offer 3 sizes in both Stainless Steel and Black Powder Coated.



Stackable Round Single Flue Chimney Caps for Masonry Chimneys - Black Powder Coated - CA 5/8
Call for price
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - Black Powder Coated - CA 5/8 Image

Stackable Round Single Flue Chimney Caps for Masonry  Chimneys Black Powder Coated – California 5/8″ Mesh (6 Year Guarantee)

Once in a while you run into a round flue liner in a masonry chimney. Generally this is handled with one of the Universal Caps, but sometimes your customers prefer a round cap on a round flue, so we offer 3 sizes in both Stainless Steel and Black Powder Coated.

TGK Square Roof Duct
Call for price
TGK Square Roof Duct Image

TGK (square)

Roof vent TGK (square) has been specially developed for DTH and DTV roof fans. Together the roof fan and roof vent form an elegant architectural whole. The roof fan is mounted directly on top of the roof vent. The base can be mounted with a diffusor or the vent can be extended with a duct or T-pipe.

Externally, TGK is constructed from galvanised sheet, and under it 50 mm mineral wool, fine-mesh fabric and an internal galvanised perforated sheet. The roof vent can be supplied with an internal cable duct. Optional bracket. Warranty is void if the bracket is not mounted in accordance with the instructions.

TGK is supplied as standard in 3 lengths and 6 sizes with PERFORM flashing appropriate to the roof pitch. TGR/TGK is also available with zinc flashing. Must be stated on order.

DAMPER AND EXTRACTOR FITTING

DimensionsTGK, diameter

DTV/DTH 160 200 250 315 400 450
Standard integrated AOR size 160 200 250 315 400 450

Roof fan

 Roof vent

Dimensions

 Weight*

Size Size

C1

C
mm

L1
mm

kg

 DTV/DTH160 TGK160 – 600  Ø160 267  600  12
TGK160 – 900  Ø160 267  900  15
TGK160 – 1200  Ø160 267  1200  19
 DTV/DTH200 TGK200 – 600  Ø200 307 600  13
TGK200 – 900  Ø200 307  900  18
TGK200 – 1200  Ø200 307  1200  22
 DTV/DTH250 TGK250 – 600  Ø250 357  600  17
TGK250 – 900  Ø250 357  900  21
TGK250 – 1200  Ø250 357  1200  28
DTV/DTH315 TGK315 – 600  Ø315 422  600  21
TGK315 – 900  Ø315 422  900  28
TGK315 – 1200  Ø315 422  1200  36
DTV/DTH400 TGK400 – 600  Ø400 507  600  26
TGK400 – 900  Ø400 507  900  34
TGK400 – 1200  Ø400 507  1200  42
DTV/DTH450 TGK450 – 900  Ø500 607 900  46
TGK450 – 1200  Ø500 607  1200  58

*Weight includes AOR and 30° PERFORM flashing

Max. roof pitch for length L1:
L1 = 600 mm: max 30° flashing
L1 = 900 mm: max 45° flashing
L1 = 1200 mm: max 60° flashing
Flashing can vary by ±2.5° relative to the given roof pitch



TGR Round Roof Duct
Call for price
TGR Round Roof Duct Image

TGR (round)

Roof vent TGR (round) has been specially developed for DTH roof fans. Together the roof fan and roof vent form an elegant architectural whole. The roof fan is mounted directly on top of the roof vent. The base can be mounted with a diffusor or the vent can be extended with a duct or T-pipe.

Installing a suction duct in the room enables an optimum air handling solution with minimum pressure drop and low sound levels, even at high airflow rates.

Externally, TGR is constructed from galvanised sheet, and under it 50 mm mineral wool, fine-mesh fabric and an internal galvanised perforated sheet. The roof vent can be supplied with an internal cable duct. Optional bracket. Warranty is void if the bracket is not mounted in accordance with the instructions.

The roof vent is insulated for sound and condensation. To avoid transfer of vibrations to the roof vent, a rubber ring is mounted on the fan.

The roof vent has been designed to take an electric cable via the integral cable duct. The installation cable is inserted in the cable duct at the bottom and drawn up by the safety switch, which is not normally an EXHAUSTO delivery. The safety switch is mounted on the control panel as shown in the guide 3004346.

TGR is supplied as standard in 3 lengths and 6 sizes with PERFORM flashing appropriate to the roof pitch. TGR is also available with zinc flashing. Must be stated on order.

Accessory for DTH roof fan. Together the roof fan and roof vent form an elegant architectural whole.

  • Supplied with perform or zinc flashing
  • Available in sizes corresponding to DTH – in 3 different lengths
  • Insulated for sound and condensation

DAMPER AND EXTRACTOR FITTING

DTV/DTH 160 200 250 315 400 450
Standard integrated AOR size 160 200 250 315 400 450
Additional accessory FLD size 160 200 250 315 qty. 2
315



The Super Cap - Black - 3/4
Call for price
The Super Cap - Black - 3/4 Image

The Super Cap – Black – 3/4″ Mesh

Size 18×34

The standard Universal will fit 90% to 95% of the flues in your area. For the other 5% or 10% of the chimneys we have other Universal type Chimney caps.

The SUPER CAP has an 18″x34″ base and covers anything down to 11″x27″. The crossbars aren’t welded in on this chimney cap, so you can place them where you need them.

Note: The crossbars are held in place by the pressure of the anchors, which is true of all Universals. We just tack weld them on so they don’t flop all over the place.



This cap has a wide range of applications.

The Super Cap - Black - California 5/8
Call for price
The Super Cap - Black - California 5/8 Image

The Super Cap – Black – California 5/8″ Mesh

Size 18×34

Chimney Products #101 and #103 Universal Chimney Caps will cover 95% of the masonry flues in California. For the other 5%, we have other Universal type Chimney caps.

The SUPER CAP has an 18″x34″ base and covers anything down to 11″x27″. The crossbars aren’t welded in on this chimney cap, so you can place them where you need them.

Note: The crossbars are held in place by the pressure of the anchors, which is true of all Universals. We just tack weld them on so they don’t flop all over the place.

This cap has a wide range of applications.

The Super Cap - Stainless Steel - 3/4
Call for price
The Super Cap - Stainless Steel - 3/4 Image

The Super Cap – Stainless Steel 3/4″ Mesh

Size 18×34

The standard Universal will fit 90% to 95% of the flues in your area. For the other 5% or 10% of the chimneys we have other Universal type Chimney caps.

The SUPER CAP has an 18″x34″ base and covers anything down to 11″x27″. The crossbars aren’t welded in on this chimney cap, so you can place them where you need them.

Note: The crossbars are held in place by the pressure of the anchors, which is true of all Universals. We just tack weld them on so they don’t flop all over the place.

This cap has a wide range of applications.

The Super Cap - Stainless Steel - California 5/8
Call for price
The Super Cap - Stainless Steel - California 5/8 Image

The Super Cap – Stainless Steel – California 5/8″ Mesh

Size 18×34



Chimney Products #101 and #103 Universal Chimney Caps will cover 95% of the masonry flues in California. For the other 5%, we have other Universal type Chimney caps.

The SUPER CAP has an 18″x34″ base and covers anything down to 11″x27″. The crossbars aren’t welded in on this chimney cap, so you can place them where you need them.

Note: The crossbars are held in place by the pressure of the anchors, which is true of all Universals. We just tack weld them on so they don’t flop all over the place.

This cap has a wide range of applications.

Universal Chimney Cap for the Midwest and Northeast
Call for price
Universal Chimney Cap for the Midwest and Northeast Image

Universal Chimney Cap for the Midwest and Northeast

Black Powder Coated Galvanized (6 Year Guarantee) – 3/4″ Mesh

If your service area has 8″x13″, 12″x12″, 13″x13″ and a lot of chimneys without raised flue liners, this is the cap for you and your customers. They get a quality chimney cap with huge screen area (3/4″ mesh) for its size and you only have to carry one cap.

* Comes in either a single box or economical 5-pack

* A Universal damper kit can be installed inside the cap when it’s needed. Anything the cap fits, so does the damper.

* Use the multi-cage lid to create chimney caps for those odd size flues.

The Universal’s unique inside and anchoring system is designed with windy conditions in mind.

Also comes in 304 Stainless Steel Universal (Lifetime Guarantee) and Copper.

Universal Chimney Cap for the Midwest and Northeast
Call for price
Universal Chimney Cap for the Midwest and Northeast Image

Universal Chimney Cap for the Midwest and Northeast

304 Stainless Steel (Lifetime Guarantee) – 3/4″ Mesh

If your service area has 8″x13″, 12″x12″, 13″x13″ and a lot of chimneys without raised flue liners, this is the cap for you and your customers. They get a quality chimney cap with huge screen area (3/4″ mesh) for its size and you only have to carry one cap.

* Comes in either a single box or economical 5-pack

* A Universal damper kit can be installed inside the cap when it’s needed. Anything the cap fits, so does the damper.

* Use the multi-cage lid to create chimney caps for those odd size flues.

The Universal’s unique inside and anchoring system is designed with windy conditions in mind.

Also comes in Black Powder Coated Galvanized (6 Year Guarantee) and Copper.

Universal Chimney Cap for the Midwest and Northeast - Copper
Call for price
Universal Chimney Cap for the Midwest and Northeast - Copper Image

Copper Universal Chimney Cap
3/4″ Mesh

If your service area has 8″x13″, 12″x12″, 13″x13″ and a lot of chimneys without raised flue liners, this is the cap for you and your customers. They get a quality chimney cap with huge screen area (3/4″ mesh) for its size and you only have to carry one cap.

* A Universal damper kit can be installed inside the cap when it’s needed. Anything the cap fits, so does the damper.



Universal Chimney Cap for the Other 5% or 10% - Stainless Steel - 3/4
Call for price
Universal Chimney Cap for the Other 5% or 10% - Stainless Steel - 3/4 Image

Universal Chimney Cap for the Other 5% or 10% Stainless Steel (Lifetime Guarantee) – 3/4″ Mesh

The standard Universal will fit 90% to 95% of the flues in your area. For the other 5% or 10% of the chimneys we have other Universal type Chimney caps.

In 18″x18″ and 22″x22″

Because a Universal chimney cap gives you 7” full inches of adjustment, the 18”x18”
covers down to 11”x11” and the 22”x22” covers down to 15”x15”.

Universal Chimney Cap for the South and Southwest - 304 Stainless Steel - 3/4
Call for price
Universal Chimney Cap for the South and Southwest - 304 Stainless Steel - 3/4 Image

Universal Chimney Cap for the South and Southwest (13×18) 304 Stainless Steel 3/4″ Mesh

LIFETIME GUARANTEE

If your service area has 8″x17.5″, 13″x17.5″, 13″x13″ or a lot of chimneys without raised flue liners, this is the cap for you and your customers. They get a quality chimney cap with huge screen area (3/4″ mesh) for its size and you only have to carry one cap.

* Comes in either a single box or economical 4-pack

* A Universal damper kit can be installed inside the cap when it’s needed. Anything the cap fits, so does the damper. All Stainless Steel.

* A Universal damper kit can be installed inside the cap when it’s needed. Anything the cap fits, so does the damper. All Stainless Steel.

The Universal’s unique inside and anchoring system is great for windy conditions.

lso comes in Black Powder Coated Galvanized Universal (6 Year Guarantee.

Universal Chimney Cap for the South and Southwest - Black Galvanized
Call for price
Universal Chimney Cap for the South and Southwest - Black Galvanized Image

Universal Chimney Cap for the South and Southwest (13×18) Black Powder Coated Galvanized 3/4″ Mesh

6 YEAR GUARANTEE

If your service area has 8″x17.5″, 13″x17.5″, 13″x13″ or a lot of chimneys without raised flue liners, this is the cap for you and your customers. They get a quality chimney cap with huge screen area (3/4″ mesh) for its size and you only have to carry one cap.

* Comes in either a single box or economical 4-pack

* A Universal damper kit can be installed inside the cap when it’s needed. Anything the cap fits, so does the damper.

* A Universal damper kit can be installed inside the cap when it’s needed. Anything the cap fits, so does the damper.

The Universal’s unique inside and anchoring system is great for windy conditions.

Also comes in Stainless Steel (Lifetime Guarantee).

Universal Damper Kit - 304 Stainless Steel
Call for price
Universal Damper Kit - 304 Stainless Steel Image

Universal Damper Kit – 304 Stainless Steel
(Lifetime Guarantee)

The Universal Damper-Kit fits inside the Universal chimney cap to make a cap-damper. The damper can be shut to seal the chimney. Because of its adjustable HI-Temp fiberglass gasket installer it can fit most chimney flues. Anything the Universal Cap will fit, so will the damper!

Four sizes are available: 13″x13″, 13″x18″, 18″x18″, and the California 13″x20.5″ damper kits are all 304 stainless steel and come with a LIFETIME GUARANTEE.

Damper plate closes against fiberglass gasket (white) for a tight seal (screen removed for demo).

You could be losing $350.00 or more out of your chimney, every year, without even knowing it.

Huge heat loss occurs when a chimney’s damper doesn’t seal properly or is missing or broken. You can’t see it, the heat just goes out of the house. If your chimney’s damper isn’t sealing properly it’s like leaving a front door open in the middle of winter.

Ventinox
Call for price
VVR Wall Fan
Call for price
VVR Wall Fan Image

VVR Overview



Capacity m3/h
Min. Max.
VVR160-4-1 60 370
VVR200-4-1 130 860
VVR250-4-1EC 250 1,900
VVR315-4-1EC 470 3,360

Design

VVR is made from cast aluminium, giving it a high corrosion resistance. It is painted in black RAL7021.



Vertical Exhaust

VVR is an extract fan with a vertical exhaust.

The design ensures an optimum air handling solution with minimum noise.

Fan Impeller

VVR wall fan is ideal for ventilation tasks requiring efficient and economical ventilation.

The specially developed centrifugal impeller with backward curved blades ensures high efficiency and low operating costs.

Service

VVR roof fan is easy to open for cleaning and maintenance.

Guide Panel

If there is a high level of humidity in the extract air, the VVR wall fan can be ordered with a guide panel.

The guide panel ensures that moisture does not run down the wall but is guided away from it.

Motor Types

VVR wall fan

VVR is available with 2 motor types:

  • Single-phase voltage controlled motor
  • EC motor

The motors are made to protection class IP54 and all materials are as a minimum class F (155 °C). The motor  has integral current overload protection.


EC motor

The EC motor is a highly efficient permanent-magnet motor of class IE5 with motor control for a 1 x 230 V connection. The motor control has been specially developed for compatibility with the EXHAUSTO DTV roof fan and, when used with this motor, ensures the lowest possible operating costs.

The motor control protects the motor from overloading, blocking, over and under voltage, and over heating. It is factory programmed by EXHAUSTO for optimal operation of the fan. It only has to be connected to a 1 X 230 VAC supply and to an EXHAUSTO EFC1P or MAC12 controller.

The motor controls also provide a Modbus interface for fan control and alarm read-offs etc.


Single-phase motor

Single-phase motors can be selected for VVR160/VVR200. All motors are 4-pole with 1400 rpm, and permit direct voltage control using EXHAUSTO EFC16, EFC35 and MAC12 controllers (with MPR4/MPR8 module).

Chimney
Air Insulated Caps for Metal Chimneys - 1 Image
Air Insulated Caps for Metal Chimneys - 1
Air Insulated Caps for Metal Chimneys 1″ Mesh for Outside California This chimney cap is designed for air-insulated chimneys (double or triple wall). It has a tight, friction-fit which we recommend you also use with sili... Read More
Call for price
Air Insulated Caps for Metal Chimneys - CA 1/2 Image
Air Insulated Caps for Metal Chimneys - CA 1/2
Air Insulated Caps for Metal Chimneys California 1/2″ Mesh This chimney cap is designed for air-insulated chimneys (double or triple wall). It has a tight, friction-fit which we recommend you also use with silicone to ke... Read More
Call for price
Animal Guards - 304 Stainless Steel - 3/4 Image
Animal Guards - 304 Stainless Steel - 3/4
Animal Guards – 304 Stainless Steel – 3/4″ Mesh Stackable 4″ Screen Height Masonry chimney caps are good for keeping out the rain but they need animal guard to keep all the critters outside and the sparks inside. S... Read More
Call for price
Animal Guards - Black Galvanized - 3/4 Image
Animal Guards - Black Galvanized - 3/4
Animal Guards Black Galvanized – 3/4″ Mesh Stackable 4″ Screen Height Masonry chimney caps are good for keeping out the rain but they need animal guard to keep all the critters outside and the sparks inside. So if your are... Read More
Call for price
BESB box ventilators Image
BESB box ventilators
BESB BOX VENTILATORS BESB box ventilators are made from Aluzinc® AZ185 class C4 in accordance with EN/ISO12944-2 and insulated for sound and condensation with 50 mm mineral wool. ... Read More
Call for price
BESB250 Box Ventilator Image
BESB250 Box Ventilator
BESB250-4-1 and BESB250-4-1EC Technical Data MODEL ... Read More
Call for price
BESB315 Box Ventilator Image
BESB315 Box Ventilator
BESB315-4-1EC Technical Data MODEL BESB315-4-1EC ... Read More
Call for price
BESB400 Box Ventilator Image
BESB400 Box Ventilator
BESB400 Technical Data MODEL BESB400-4-1EC ... Read More
Call for price
BESB500 Box Ventilator Image
BESB500 Box Ventilator
BESB500-4-1EC and BESB500-4-3EC Technical Data MODEL  BESB... Read More
Call for price
BESF Box Ventilator Image
BESF Box Ventilator
BESF box ventilators Overview   ... Read More
Call for price
BESF146 Box Ventilator Image
BESF146 Box Ventilator
BESF146 MODEL BESF146-4-1 ... Read More
Call for price
BESF160 Box Ventilator Image
BESF160 Box Ventilator
BESF160-2-1EC and BESF160-4-1 Technical Data MODEL ... Read More
Call for price
BESF180 Box Ventilator Image
BESF180 Box Ventilator
BESF180-4-1EC Technical Data MODEL BESF180-4-1EC... Read More
Call for price
BESF200 Box Ventilator Image
BESF200 Box Ventilator
BESF200-4-1EC Technical Data MODEL BESF200-4-1EC... Read More
Call for price
BESF225 Box Ventilator Image
BESF225 Box Ventilator
BESF225-4-1EC Technical Data MODEL BESF225-4-1EC... Read More
Call for price
BESF250 Box Ventilator Image
BESF250 Box Ventilator
BESF250-4-1EC Technical Data MODEL BESF250-4-1EC... Read More
Call for price
BESF280 Box Ventilator Image
BESF280 Box Ventilator
BESF280-4-3 and BESF280-4-3EC Technical Data MODEL ... Read More
Call for price
Butterfly Cap-Damper Image
Butterfly Cap-Damper
Butterfly Cap-Damper LIFETIME GUARANTEE! Just like the Butterfly damper, the Butterfly Cap-Damper gives you access to the chimney with the removal of a couple of wingnuts (below). Because of its design, t... Read More
Call for price
Butterfly Damper Image
Butterfly Damper
Butterfly Damper Lifetime Guarantee  Chimney Products Inc. top-sealing Butterfly Damper is great for those chimneys that don’t have a raised flue liner, under Multi-Flue chimney caps, or as a low pro... Read More
Call for price
California Universal Chimney Cap - Black Galvanized - 5/8 Image
California Universal Chimney Cap - Black Galvanized - 5/8
California Universal Chimney Cap – Black Galvanized – 5/8″ Mesh California Universal Chimney Cap Black Galvanized – 5/8″ Mesh The “101”, “Premie”, “Galvie”, “The Black One”, “The one I ... Read More
Call for price
California Universal Chimney Cap - Copper - 5/8 Image
California Universal Chimney Cap - Copper - 5/8
California Universal Chimney Cap – Copper – 5/8″ Mesh Size – 13×20.5 Lifetime Guarantee! California Universal Chimney Cap in Copper! For those folks who want the top of the line, you can’t beat copper. Ov... Read More
Call for price
California Universal Chimney Cap - Stainless Steel - 5/8 Image
California Universal Chimney Cap - Stainless Steel - 5/8
California Universal Chimney Cap Stainless Steel – 5/8″ Mesh Exactly the same chimney cap as Chimney Products “101” only constructed of 304 Stainless Steel with a Lifetime Guarantee! In Californi... Read More
Call for price
California Universal Chimney Cap-Black Stainless Steel - 5/8 Image
California Universal Chimney Cap-Black Stainless Steel - 5/8
California Universal Chimney Cap Black Stainless Steel – 5/8″ Mesh Size 13×20.5 Called the Black Beauty, exactly the same chimney cap as the “101” only constructed of 304 Stainless Steel with a Lifetime Guar... Read More
Call for price
California Universal Specialty Cap - Black - 5/8 Image
California Universal Specialty Cap - Black - 5/8
California Universal Specialty Cap – Black – 5/8″ Mesh ... Read More
Call for price
California Universal Specialty Cap - Copper - 5/8 Image
California Universal Specialty Cap - Copper - 5/8
California Universal Specialty Cap – Copper – 5/8″ Mesh   Size 13×13 Because the California Universal only fits about 95% of masonry chimneys in California, Chimney Products has some caps to fit the rem... Read More
Call for price
California Universal Specialty Cap - Stainless Steel - 5/8 Image
California Universal Specialty Cap - Stainless Steel - 5/8
California Universal Specialty Cap – Stainless Steel – 5/8″ Mesh   Because the California Universal only fits about 95% of masonry chimneys in California, Chimney Products has some caps to fit the remaining 5%.... Read More
Call for price
Covers Roman Image
Call for price
Covers Tudor Image
Call for price
Drop-In Damper - 304 Stainless Steel Image
Drop-In Damper - 304 Stainless Steel
Drop-In Damper – 304 Stainless Steel Drop-In Damper – 304 Stainless Steel The all 304 Stainless Steel DROP-IN DAMPERS can be used with most existing chimney caps. Just remove the cap, drop in the damper or sl... Read More
Call for price
DTH 160 Roof Fan Horizontal Exhaust Image
DTH 160 Roof Fan Horizontal Exhaust
DTH160 Technical Data MODEL ... Read More
Call for price
DTH Roof Fan Horizontal Exhaust Image
DTH Roof Fan Horizontal Exhaust
DTH Overview   Capacity m3... Read More
Call for price
DTH200 Roof Fan Horizontal Exhaust Image
DTH200 Roof Fan Horizontal Exhaust
DTH200 Technical Data MODEL DTH200-4-1 ... Read More
Call for price
DTH250 Roof Fan Horizontal Exhaust Image
DTH250 Roof Fan Horizontal Exhaust
DTH250 Technical Data The motor controller for the EC motor is supplied in a black box for fixing to the roof vent. NB: Due to EMC requirements the cable be... Read More
Call for price
DTH315 Roof Fan Horizontal Exhaust Image
DTH315 Roof Fan Horizontal Exhaust
DTH315 Technical Data The motor controller for the EC motor is supplied in a black box for fixing to the roof vent. NB: Due to EMC requirements the cable be... Read More
Call for price
DTH400 Roof Fan Horizontal Exhaust Image
DTH400 Roof Fan Horizontal Exhaust
DTH400 Technical Data The motor controller for the EC motor is supplied in a black box for fixing to the roof vent. NB: Due to EMC requirements the cable be... Read More
Call for price
DTV 160 Roof Fan Vertical Exhaust Image
DTV 160 Roof Fan Vertical Exhaust
DTV160 Technical Data MODEL ... Read More
Call for price
DTV Roof Fan Vertical Exhaust Image
DTV Roof Fan Vertical Exhaust
DTV Overview   Capacity m3... Read More
Call for price
DTV200 Roof Fan Vertical Exhaust Image
DTV200 Roof Fan Vertical Exhaust
DTV200 Technical Data MODEL ... Read More
Call for price
DTV250 Roof Fan Vertical Exhaust Image
DTV250 Roof Fan Vertical Exhaust
DTV250-4-1EC Technical Data MODEL DTV250-4-1EC... Read More
Call for price
DTV315 Roof Fan Vertical Exhaust Image
DTV315 Roof Fan Vertical Exhaust
DTV315-4-1EC Technical Data MODEL DTV315-4-1EC... Read More
Call for price
DTV400 Roof Fan Vertical Exhaust Image
DTV400 Roof Fan Vertical Exhaust
DTV400 Tehcnical Data MODEL DTV400-4-1EC ... Read More
Call for price
DTV450 Roof Fan Vertical Exhaust Image
DTV450 Roof Fan Vertical Exhaust
DTV450 Technical Data MODEL DTV450-4-1EC ... Read More
Call for price
Ice Breaker Chimney Cap-Damper - 3/4 Image
Ice Breaker Chimney Cap-Damper - 3/4
The “Ice Breaker” Chimney Cap-Damper 3/4″ MESH SINGLE FLUE CAP-DAMPER (LIFETIME GUARANTEE) Chimney Product’s Lifetime Guarantee Cap-Damper. The same sturd... Read More
Call for price
Modular Chimney Caps - Stainless Steel - 3/4 Image
Modular Chimney Caps - Stainless Steel - 3/4
The Modular Chimney Cap Stainless Steel – 3/4″ Mesh, 12″ Screen Height Modular: Composed of standardized units or sections for easy construction or flexible arrangement. Tired of ordering custom caps? Tired of deal... Read More
Call for price
Modular Chimney Caps - Stainless Steel - California 5/8 Image
Modular Chimney Caps - Stainless Steel - California 5/8
The Modular Chimney Cap Stainless Steel – California 5/8″ Mesh, 10″ Screen Height Modular: Composed of standardized units or sections for easy construction or flexible arrangement. Tired of ordering custom caps? Ti... Read More
Call for price
Modular Extensions for Stainless Steel Modular Chimney Caps - 3/4 Image
Modular Extensions for Stainless Steel Modular Chimney Caps - 3/4
Modular Extensions  for Stainless Steel Modular Chimney Caps – 3/4″ Mesh Modular: Composed of standardized units or sections for easy construction or flexible arrangement. With the Modular Chimney Caps you choose th... Read More
Call for price
Modular Extensions for Stainless Steel Modular Chimney Caps - CA 5/8 Image
Modular Extensions for Stainless Steel Modular Chimney Caps - CA 5/8
Modular Extensions  for Stainless Steel Modular Chimney Caps – California 5/8″ Mesh Modular: Composed of standardized units or sections for easy construction or flexible arrangement. With the Modular Chimney Ca... Read More
Call for price
Monsoon Cap Image
Monsoon Cap
Monsoon Cap A replacement lid for our standard chimney cap for metal chimneys that turns it into a “Monsoon Cap” to keep out driving rain. Just change them out with the one wingnut on top. The “Monsoon” cure... Read More
Call for price
Multi-Flue Chimney Caps - 304 Stainless Steel *Reversible* - 3/4 Image
Multi-Flue Chimney Caps - 304 Stainless Steel *Reversible* - 3/4
Stainless Steel *Reversible* Multi-Flue Chimney Cap  3/4″ Mesh (Lifetime Guarantee) – 10″ Screen Height All Chimney Products Multi-flue sizes have reversible panels for ease of installat... Read More
Call for price
Multi-Flue Chimney Caps - 304 Stainless Steel *Reversible* - CA 5/8 Image
Multi-Flue Chimney Caps - 304 Stainless Steel *Reversible* - CA 5/8
Stainless Steel *Reversible* Multi-Flue Chimney Cap California 5/8″ Mesh (Lifetime Guarantee) with 10″ Screen Height All Chimney Products Multi-flue sizes have reversible panels for ease of... Read More
Call for price
Multi-Flue Chimney Caps - Black *Reversible* - CA 5/8 Image
Multi-Flue Chimney Caps - Black *Reversible* - CA 5/8
Black *Reversible* Multi-Flue Chimney Cap California 5/8″ Mesh (6 Year Guarantee) – 10″ Screen Height All Chimney Products Multi-flue sizes have reversible panels for ease of install... Read More
Call for price
Multi-Flue Chimney Caps - Black Powder Coated *Reversible* - 3/4 Image
Multi-Flue Chimney Caps - Black Powder Coated *Reversible* - 3/4
Premium Black Powder Coated *Reversible* Multi-Flue Chimney Cap 3/4″ Mesh (6 Year Guarantee) – 10″ Screen Height All Chimney Products Multi-flue sizes have reversible panels for ease... Read More
Call for price
Multi-Flue Chimney Caps - Copper *Reversible* - 3/4 Image
Multi-Flue Chimney Caps - Copper *Reversible* - 3/4
Copper *Reversible* Multi-Flue Chimney Cap 3/4″ Mesh (Lifetime Guarantee) – 10″ Screen Height All Chimney Products Multi-flue sizes have reversible panels for ease of installation, lids h... Read More
Call for price
Multi-Flue Chimney Caps - Copper *Reversible* - CA 5/8 Image
Multi-Flue Chimney Caps - Copper *Reversible* - CA 5/8
Copper *Reversible* Multi-Flue Chimney Cap California 5/8″ Mesh (Lifetime Guarantee) with 10″ Screen Height All Chimney Products Multi-flue sizes have reversible panels for ease of installa... Read More
Call for price
Pots Caperose Image
Call for price
Pots Roman Image
Call for price
Pots Toppers Image
Call for price
Pots Tudor Image
Call for price
Pots Tuscan Image
Call for price
Pots Windsor Image
Call for price
Rockport Image
Call for price
Round Cap Damper Air Insulated 1/2 Image
Round Cap Damper Air Insulated 1/2
Round Cap Damper Air Insulated 1/2″ Mesh The Round Ice Breaker is just as rugged and reliable as it’s square counterpart. It is made of all 304 stainless steel. We tested it by freezing it well below freezing temperatures a... Read More
Call for price
Round Cap Damper Air Insulated 1/2 Image
Round Cap Damper Air Insulated 1/2
Round Cap Damper Air Insulated 1/2″ Mesh The Round Ice Breaker is just as rugged and reliable ... Read More
Call for price
Round Cap Damper Solid Pack 1 Image
Round Cap Damper Solid Pack 1
Round Cap Damper Solid Pack 1″ Mesh The Round Ice Breaker is just as rugged and reliable as it’s square counterpart. It is made of all 304 stainless steel. We tested it by freezing ... Read More
Call for price
Round Cap Damper Solid Pack 1 Image
Round Cap Damper Solid Pack 1
Round Cap Damper Solid Pack 1″ Mesh The Round Ice Breaker is just as rugged and reliable as it... Read More
Call for price
Round Cap Damper Solid Pack 1/2 Image
Round Cap Damper Solid Pack 1/2
Round Cap Damper Solid Pack 1/2″ Mesh The Round Ice Breaker is just as rugged and reliable as ... Read More
Call for price
Round Ice Breaker Air Insulated 1 Image
Round Ice Breaker Air Insulated 1
Round Ice Breaker Air Insulated 1″ Mesh The Round Ice Breaker is just as rugged and reliable as it’s square counterpart. It is made of all 304 stainless steel. We tested it by freezing it well below freezing temperatures an... Read More
Call for price
Single Flue Chimney Cap for Oval or Rectangular Flues - 304 Stainless Steel - CA 5/8 Image
Single Flue Chimney Cap for Oval or Rectangular Flues - 304 Stainless Steel - CA 5/8
Single Flue Chimney Cap for Oval or Rectangular Flues  304 Stainless Steel – California 5/8″ Mesh Designed for California. Made with special 5/8″ mesh just for California’s spark arrester code. Solid, rugged and... Read More
Call for price
Single Flue Chimney Cap for Oval or Rectangular Flues - Black - CA 5/8 Image
Single Flue Chimney Cap for Oval or Rectangular Flues - Black - CA 5/8
Single Flue Chimney Cap for Oval or Rectangular Flues Black Galvanized (6 Year Guarantee) – California 5/8″ Mesh Same popular design, just different material Designed for California. Made with special 5/8″ mesh j... Read More
Call for price
Single Wall/Solid-Pack Replacement Cap for Metal Chimneys - 1 Image
Single Wall/Solid-Pack Replacement Cap for Metal Chimneys - 1
Single Wall/Solid-Pack Replacement Cap for Metal Chimneys 1″ Mesh for Outside California This is the replacement cap for single wall or solid-pack metal chimney systems. These Chimney caps have a tight, friction-fit which we ... Read More
Call for price
Single Wall/Solid-Pack Replacement Cap for Metal Chimneys - CA 1/2 Image
Single Wall/Solid-Pack Replacement Cap for Metal Chimneys - CA 1/2
Single Wall/Solid-Pack Replacement Cap for Metal Chimneys – CA 1/2″ Mesh Single Wall/Solid-Pack Replacement Cap for Metal Chimneys California 1/2″ Mesh This is the replacement cap for single wall or solid-pa... Read More
Call for price
Solid Frame Chimney Cap - 304 Stainless Steel - Stackable 3/4 Image
Solid Frame Chimney Cap - 304 Stainless Steel - Stackable 3/4
304 Stainless Steel Solid Frame Chimney Cap Stackable 3/4″ Mesh (Lifetime Guarantee) Solid, reliable heavy-duty all 304 stainless steel, 24-gauge stamped lid, 18-gauge expanded metal mesh, an... Read More
Call for price
Solid Frame Chimney Cap - Black Powder Coated - Stackable 3/4 Image
Solid Frame Chimney Cap - Black Powder Coated - Stackable 3/4
Black Powder Coated Solid Frame Chimney Cap Stackable 3/4″ Mesh (6 Year Guarantee) The same solid, reliable, heavy-duty chimney cap as our 304 Stainless Steel only in a more economical materi... Read More
Call for price
Solid Frame Chimney Cap - Copper - 3/4 Image
Solid Frame Chimney Cap - Copper - 3/4
Copper Solid Frame Chimney Cap Stackable 3/4″ Mesh (Lifetime Guarantee) Copper is the top-of-the-line. As the copper ages it gives that unique antique look (patina). Both Stackable Solid Fram... Read More
Call for price
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - 304 Stainless Steel - 3/4 Image
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - 304 Stainless Steel - 3/4
Stackable Round Single Flue Chimney Caps for Masonry Chimneys 304 Stainless Steel (Lifetime Guarantee) – 3/4″ Mesh Once in a while you run into a round flue liner in a masonry chimney. Generally this is handled with one of ... Read More
Call for price
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - 304 Stainless Steel - CA 5/8 Image
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - 304 Stainless Steel - CA 5/8
Stackable Round Single Flue Chimney Caps for Masonry Chimneys 304 Stainless Steel (Lifetime Guarantee) – California 5/8″ Mesh Once in a while you run into a round flue liner in a masonry chimney. Generally this is h... Read More
Call for price
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - Black Powder Coated - 3/4 Image
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - Black Powder Coated - 3/4
Stackable Round Single Flue Chimney Caps for Masonry Chimneys Black Powder Coated – 3/4″ Mesh (6 Year Guarantee) Once in a while you run into a round flue liner in a masonry chimney. Generally this is handled with one of th... Read More
Call for price
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - Black Powder Coated - CA 5/8 Image
Stackable Round Single Flue Chimney Caps for Masonry Chimneys - Black Powder Coated - CA 5/8
Stackable Round Single Flue Chimney Caps for Masonry  Chimneys Black Powder Coated – California 5/8″ Mesh (6 Year Guarantee) Once in a while you run into a round flue liner in a masonry chimney. Generally this is handled w... Read More
Call for price
TGK Square Roof Duct Image
TGK Square Roof Duct
TGK (square) Roof vent TGK (square) has been specially developed for DTH and DTV roof fans. Together the roof fan and roof vent form an elegant architectural whole. The roof fan is mounted directly on top of the roof vent. The ... Read More
Call for price
TGR Round Roof Duct Image
TGR Round Roof Duct
TGR (round) Roof vent TGR (round) has been specially developed for DTH roof fans. Together the roof fan and roof vent form an elegant architectural whole. The roof fan is mounted directly on top of the roof vent. The base can be... Read More
Call for price
The Super Cap - Black - 3/4 Image
The Super Cap - Black - 3/4
The Super Cap – Black – 3/4″ Mesh Size 18×34 ... Read More
Call for price
The Super Cap - Black - California 5/8 Image
The Super Cap - Black - California 5/8
The Super Cap – Black – California 5/8″ Mesh Size 18×34 ... Read More
Call for price
The Super Cap - Stainless Steel - 3/4 Image
The Super Cap - Stainless Steel - 3/4
The Super Cap – Stainless Steel 3/4″ Mesh Size 18×34 The standard Universal will fit 90% to 95% of the flues in your area. For the other 5% or 10% of the chimneys we have other Universal type Chimney caps. T... Read More
Call for price
The Super Cap - Stainless Steel - California 5/8 Image
The Super Cap - Stainless Steel - California 5/8
The Super Cap – Stainless Steel – California 5/8″ Mesh Size 18×34   Chimney Products #101 and #103 Universal Chimney Caps will cover 95% of the masonry flues in California. For the other 5%, we have o... Read More
Call for price
Universal Chimney Cap for the Midwest and Northeast Image
Universal Chimney Cap for the Midwest and Northeast
Universal Chimney Cap for the Midwest and Northeast Black Powder Coated Galvanized (6 Year Guarantee) – 3/4″ Mesh If your service area has 8″x13″, 12″x12″, 13″x13?... Read More
Call for price
Universal Chimney Cap for the Midwest and Northeast Image
Universal Chimney Cap for the Midwest and Northeast
Universal Chimney Cap for the Midwest and Northeast 304 Stainless Steel (Lifetime Guarantee) – 3/4″ Mesh If your service area has 8″x13″, 12″x12″, 13″x13″ and a l... Read More
Call for price
Universal Chimney Cap for the Midwest and Northeast - Copper Image
Universal Chimney Cap for the Midwest and Northeast - Copper
Copper Universal Chimney Cap 3/4″ Mesh If your service area has 8″x13″, 12″x12″, 13″x13″ and a lot of chimneys without raised flue liners, this is the cap for you and your customers. T... Read More
Call for price
Universal Chimney Cap for the Other 5% or 10% - Stainless Steel - 3/4 Image
Universal Chimney Cap for the Other 5% or 10% - Stainless Steel - 3/4
Universal Chimney Cap for the Other 5% or 10% Stainless Steel (Lifetime Guarantee) – 3/4″ Mesh The standard Universal will fit 90% to 95% of the flues in your area. For the other 5% or 10% of the chimneys we have other Univ... Read More
Call for price
Universal Chimney Cap for the South and Southwest - 304 Stainless Steel - 3/4 Image
Universal Chimney Cap for the South and Southwest - 304 Stainless Steel - 3/4
Universal Chimney Cap for the South and Southwest (13×18) 304 Stainless Steel 3/4″ Mesh LIFETIME GUARANTEE If your service area has 8″x17.5″, 13″x17.5″, 13″x13″ or a lot... Read More
Call for price
Universal Chimney Cap for the South and Southwest - Black Galvanized Image
Universal Chimney Cap for the South and Southwest - Black Galvanized
Universal Chimney Cap for the South and Southwest (13×18) Black Powder Coated Galvanized 3/4″ Mesh   6 YEAR GUARANTEE If your service area has 8″x17.5″, 13″x17.5″, 13″x1... Read More
Call for price
Universal Damper Kit - 304 Stainless Steel Image
Universal Damper Kit - 304 Stainless Steel
Universal Damper Kit – 304 Stainless Steel (Lifetime Guarantee) The Universal Damper-Kit fits inside the Universal chimney cap to make a cap-damper. The damper can be shut to seal the chimney. Because of its adjustable H... Read More
Call for price
Ventinox Image
Call for price
VVR Wall Fan Image
VVR Wall Fan
VVR Overview   Capacity m3/h... Read More
Call for price

Search by Brandname

36
Yes
None
1
1000000
Search...
/products/
